NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH

3.1.6.2 Firmware

From the Advanced settings menu, press [6] to display the Firmware menu. (From Administrator main menu press [7]-[6])

The Firmware menu has three possible functions:

Function

1. About Firmware

2. Load new firmware

3. Save current firmware

3.1.6.2.1 Load new firmware

To upgrade the firmware that controls the Console Switch, as soon as improved versions become available, download the

firmware file (from the NTI website at www.networktechinc.com) to a local CPU, and follow the instructions under "Firmware

Upgrade" on pg 32 to install it.

3.1.6.2.2 Save current firmware

In order to save the firmware currently in SERIMUX, perhaps before installing new firmware, from the Firmware menu:

press [3] for Save current firmware. The message shown in Fig.19 will appear.

Note: In order to save the current firmware, the user must be using a CPU connected through port 1 (as described under

"Firmware Upgrade" on page 32.

Description

Provides information about SERIMUX including revision number, code length, and CRC

Initiate firmware upgrade (see Firmware Upgrade pg 32)

Save present firmware in SERIMUX to binary file
