NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH

3.2. User Controls

Users can connect only to accessible ports as defined by the administrator. A list of those ports will be displayed with a
successful login. Connection can be made using the TERMINAL, or a serial terminal with an emulator (e.g. Windows
HyperTerminal) connected to the SERIMUX at an allowed user port
To login, press the [Spacebar] or [Enter] key. Users can login by entering a valid name and password, assigned by the
administrator. When prompted for a "User name:", type the administrator assigned user name and press [Enter]. When
prompted for the "Password:", type the administrator assigned password and press [Enter].
Note: User names and passwords are case sensitive. It is important to know what characters must be capitalized and
what characters must not.
FYI: The administrator may select a user that will automatically login at power up (User 1 is setup by default). In this
case, neither name nor password will be required, just press [Spacebar] or [Enter] after powering ON the TERMINAL or
opening the connected terminal emulator.
After login, the user may connect to an allowed host port, or view host status and parameters. The user is unable to modify port
parameters unless the user has been granted administrative privileges.

3.2.1 User "Accessible host list" screen

After successful login, the "Accessible host list" will be displayed. The administrator may choose another initial screen to be
displayed, following user's preferences. The Accessible host list includes:
• user index number and name
• index number and name of the login port
• index numbers and names of accessible hosts
From the "Accessible host list", the user can perform the following functions:
Function
Connect to host
Refresh the screen
Logout
FYI: The port index numbers are 2-digit decimal numbers. If the wrong number is entered, simply enter the correct
number. Only the last two numbers entered before the [Enter] key is pressed will be accepted. The [Enter] key
validates the command; [Esc] or [Spacebar] cancels it.

Figure 20- A user with limited host port access

Keystroke
[xx] - [Enter] (where xx is the port index number)
[Spacebar]
[Esc] or [Ctrl]+[X] , then [Y] to confirm
26
