NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH
3.1.3.1.10 Copy Port Serial Settings
– Press [+] to select the current port as source in a port settings copy-paste process (except port 0).
– Then, press [*] to paste the port settings.
– Press [Y] to paste the selected port settings to the current port, [A] to paste to all ports, [S] to specify the
destination port, or press any other key to cancel.
3.1.3.1.11 Display serial settings for different port number
Press [>] (greater than symbol) to display the next higher port serial settings, or press [<] (less than symbol) to display the
previous port serial settings.
Press [Esc] or [Space] to return to the "Port settings" menu.

3.1.3.2 Modem settings

From the "Port settings" menu, press [6] to display the "Modem settings" menu.
Remote connections are possible if modems are used, usually by the users. The remote modem may call in to a local modem
attached to a SERIMUX port. A minimum number of port modem settings can be adjusted in the SERIMUX to control the
connection (try the default values first; refer to the manual(s) for the modems otherwise).
The administrator can initialize a modem attached to a SERIMUX port, or disconnect the modem. To control the modem
connection from the "Modem settings" menu, the following functions are possible:
Function
Attach and initialize a modem
Disconnect a modem
Change the modem reset string
Change the initialization string
Change the hangup string
Enable hangup on "NO CARRIER"
Save the changes
Cancel the command
Reset to default values
.
– Press [+] to select the current port as source in a port modem settings copy-paste process (except port 0).
– Then, press [*] to paste the port settings.
– Press [Y] to paste the selected port settings to the current port, [A] to paste to all ports, [S] to specify the
destination port, or press any other key to cancel.

Figure 12- Modem settings menu

Keystroke
[1] - [A]
FYI: If an old modem is attached to a SERIMUX port, it may
[1] - [D]
be necessary to enable the "Hang-up on "NO CARRIER"
[2]
message" option, in order to hang-up and disconnect the
[3]
attached modem when receiving this message. Press [5],
[4]
then [Y] to enable or any other key to disable this option.
[5]
Usually, this option should remain disabled.
[Enter]
[Esc]
[0]-[Y]
