NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH

5. HARDWARE INFORMATION

Introduction
This chapter provides information on hardware specifications, pinouts for the Ethernet cable, pinouts for port connectors, and
pinouts for the cable adapters.

5.1 Hardware Specifications

Physical
Size (In.) WxDxH
Weight
Operating temperature
Storage temperature
Humidity
Power Supply
Power Consumption
Power requirements
Rack mount kit
LCD Panel Specifications
Screen size
Resolution
Controls
Brightness
Contrast
Viewing Angle
Keyboard Specifications
Type
Layout
Terminal Emulation
Emulations
Character matrix
Screen size
Page length
Cursor
Modes
Color modes
Communication Ports
Network port
Local printer ports
Serial baud rates
Data format
Serial handshake
Communications options
Serial Interface
Number of ports
Connectors
Data
Parity
Stop Bits
Flow Control
Baud Rate
19x18.4x1.75
23.3 lbs.
32°F - 100°F (0°C - 38°C)
-20°F to 140°F (-29°C to 60°C)
17% to 90% non condensing
Auto -ranging 90-262 VAC, 47-63Hz
60W (max), <25W (standby)
100-240VAC, 50 or 60Hz
Included for Sun & most EIA 19" racks
15.1" visible diagonal
800x600
contrast, brightness, auto-adjust, color temperature
250cd/m (typical)
500:1 (typical)
140° H / 125° V
83 key
US
VT52, VT100, VT220, Console ANSI, PC TERM, TVI910+/925, WY-50+, WY-60, WY-100, WY-
120, WY-325, PCG Alpha
7x12 dot matrix in 10x16 cell with 3 dot descenders
80x25
1, 2, or 4 screens (multiple screen page length reduces maximum number of possible telnet
sessions)
Blink or steady, block or underline
Full duplex, half duplex, block mode, half block mode
16 foreground and 16 background colors
One RJ45 10Base-T Ethernet port
One DB25F Parallel and one DB9M RS232 port
50 to 115,200 bps
7 or 8 data bits with or without parity, 1 or 2 stop bits
XON/XOFF, XPC, and hardware DTR
Single RS232 server connection, or up to 16 Ethernet telnet sessions to predefined IP addresses.
Both serial and Ethernet connections can not be used concurrently.
4 or 8 RS232 ports
RJ45 male
asynchronous, 5, 6, 7, or 8 bits per character
even, odd, or none
1, 1 , or 2 bits
Xon/Xoff, RTS/CTS, Both, or None
50 bps to 128,000 bps
