- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Fax:330-562-1999 Aurora, OH 44202 INCORPORATED www.networktechinc.com ® RACKMUX Series RACKMUX-V15/17 RACKMUX-D15/17 Rackmount Drawer with Keyboard, LCD Monitor and Mouse Installation and Operation Manual MAN047 Rev Date 8/6/2007...
- Page 2 TRADEMARK RACKMUX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2007 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
Brightness/Contrast Menu ............................8 Color Menu ................................8 Position Menu ................................8 Setup Menu................................9 Keyboard Functions ..............................10 RACKMUX-V15 ................................. 10 Number Pad................................11 Other Functions of the "Fn" Key ..........................12 Numeric Keypad Option............................. 12 SUN Keyboard Keys..............................13 Power Key ................................. - Page 4 TABLE OF FIGURES Figure 1- Mount RACKMUX to a standard rack ..........................3 Figure 2- Position RACKMUX with clearance to open ........................3 Figure 3- Mount to Telco post with optional mounting brackets ......................4 Figure 4- Connect a PS/2 CPU................................4 Figure 5- Connect a USB CPU ................................
-
Page 5: Introduction
The RACKMUX-V15/-17 also provides a front panel USB 1.1 port for the connection of an external USB device (such as a flash drive). -
Page 6: Features And Functions
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE PS/2 Front View RACKMUX-V17 - or - (RACKMUX-V17) (RACKMUX-D17) Rear View RACKMUX-V17 FEATURES AND FUNCTIONS Power Button- press to turn the LCD monitor ON and OFF Power LED- Indicates operation status... -
Page 7: Installation
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE INSTALLATION Rack Mounting Instructions The RACKMUX was designed to be mounted to a rack and includes mounting flanges to make attachment easy. 1. Determine the mounting height in the rack for the drawer. -
Page 8: Optional Telco 2-Post Mounting
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE Optional Telco 2-Post Mounting If the Telco 2-post mounting bracket kit (NTI# RL-T15-TEL) is to be used, secure the short and long brackets to each side of the drawer as shown in Fig. 2. -
Page 9: Figure 5- Connect A Usb Cpu
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE REAR VIEW OF RACKMUX-V17 NETWORK TECHNOLOGIES INCORPORATED 1275 Danner Dr Tel:330-562-7070 Aurora, OH 44202 Fax:330-562-1999 www.networktechinc.com USB Type A Male USB Type B Male USB-AB-2M (supplied) VEXT-6-MM (supplied) USB CPU 15HD Male... -
Page 10: Connect Extra Device
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE Connect Extra Device On the front of the RACKMUX is an additional USB Type A port to be used, if desired, for an extra accessory. Any low or full speed USB device may be connected to this port to be used. -
Page 11: Display Functions
DISPLAY FUNCTIONS An NTI RACKMUX with a 17” monitor supports resolutions up to SXGA (1280 x 1024) with a refresh rate at between 55 and 76Hz. When a 15” monitor is present, support for resolutions up to XGA (1024 x 768) apply with a refresh rate at between 55 and 76Hz. -
Page 12: Brightness/Contrast Menu
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE Brightness/Contrast Menu Selecting the Brightness/Contrast menu will bring up a screen in which the user can adjust the brightness and contrast levels of the LCD display. Using the Up or Down arrows to navigate the menu, highlight either the BRIGHTNESS or CONTRAST sections and press the Select button to choose the option to adjust. -
Page 13: Setup Menu
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE Setup Menu Selecting the Setup menu will bring up a screen in which the user can adjust OSD POSITION-the position of the OSD menus on the LCD display OSD TIME-the length of time the user can be idle before the OSD menu automatically exits (adjustable from 10... -
Page 14: Keyboard Functions
KEYBOARD FUNCTIONS RACKMUX-V15 The keyboard on the RACKMUX-V15 (and RACKMUX–V17) is a standard condensed Windows format. To reduce the keyboard size, some keys have been assigned multiple functions, accessible via the "Fn" key. This section will describe which keys have multiple functions and how to enable them. -
Page 15: Number Pad
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE Number Pad The functionality of a Number Pad on a standard Windows keyboard has been incorporated into the keyboard of the RACKMUX-V15. To substitute the keys of the Number Pad Press the "NumLock" key. -
Page 16: Other Functions Of The "Fn" Key
Pressing the "Fn" key will lock the function, indicated by the illuminated "Fn" LED. Locking the "Fn" will not only enable the Number Pad keys (page 11) but it will also enable other standard keyboard features of the RACKMUX-V15. Key Function when Fn key is Key Function when Fn key is not locked ("Fn"... -
Page 17: Sun Keyboard Keys
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE SUN Keyboard Keys Use the chart below to type SUN’s additional keys when the "Fn" key is locked. RACKMUX Keyboard Sun Extra Keys RACKMUX Keyboard Sun Extra Keys Stop Find Again... -
Page 18: Dc Power Option
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE DC POWER OPTION If the RACKMUX has been ordered with the DC Power option (“48V” at the end of the model number), a 3-terminal block has been provided for connection to a 36-72VDC 2A power source. -
Page 19: Safety
This NTI product has been designed and fully tested with user safety of the utmost importance. As with all electronic devices, this NTI product should be handled and operated with care. In order to avoid possible injury and to reduce any risk of damage to this product, please read and follow each of these safety instructions. -
Page 20: Rackmux-Kvm Drawer Standard Specifications
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE RACKMUX-KVM DRAWER STANDARD SPECIFICATIONS General Specs Case Material..........Electro-galvanized steel black powdercoated Dimensions WxDxH (in.).......19 x 21.9 x 1.75 Supported Rack Depths………………………..Adjustable 22” – 39” Weight……………………………………………26 lbs. Input Power............AC 100-240V, 50 – 60 Hz Operating Temperature........0-40˚C... -
Page 21: Osd Control Board
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE OSD Control Board OSD Control ..........5 Keys Power Key .............Power ON/OFF Menu Key............Activates Menu Up, Down Keys ..........Navigation Control Select Key............Select (when in Menu); Auto Adjust (not in menu) LED..............Indicates Operation Status ...............Green = Power-ON, Video Input OK... -
Page 22: Troubleshooting
NTI RACKMUX-V15/17 RACKMOUNT LCD MONITOR WITH KEYBOARD AND MOUSE TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
