- Page 1 ® RACKMUX Series RACKMUX-VS17-T RACKMUX-DS17-T Rackmount Drawer with SUN Keyboard, LCD Monitor and Trackball Installation and Operation Manual MAN083 Rev Date 2/25/2008...
- Page 2 CE Statement We, Network Technologies Inc, declare under our sole responsibility that the RACKMUX-VS17-T, RACKMUX-DS17-T, RACKMUX-VS17-TN, and RACKMUX-DS17-TN are in conformity with European Standard EN55022.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Features and Functions..............................2 Installation ..................................3 Rack Mounting Instructions ............................3 Optional Telco 2-Post Mounting ..........................4 Connect to a CPU................................ 4 Connect Extra Device ..............................5 Connect Power ................................6 Power Up ..................................6 Display Functions ................................ -
Page 4: Introduction
1RU drawer can be pushed into the cabinet easily and smoothly, helping to organize and streamline busy server rooms. The NTI RACKMUX product line offers a range of KVM Drawer solutions ideal for rack and server management applications, which will ensure reliability and serviceability. -
Page 5: Features And Functions
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Compose Front View RACKMUX-VS17-T - or - (RACKMUX-VS17-T) (RACKMUX-DS17-T) Rear View RACKMUX-VS17-T FEATURES AND FUNCTIONS Power Button- press to turn the LCD monitor ON and OFF Power LED- Indicates operation status... -
Page 6: Installation
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE INSTALLATION Rack Mounting Instructions The RACKMUX was designed to be mounted to a rack and includes mounting flanges to make attachment easy. 1. Determine the mounting height in the rack for the drawer. -
Page 7: Optional Telco 2-Post Mounting
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Optional Telco 2-Post Mounting If the Telco 2-post mounting bracket kit (NTI# RL-T15-TEL) is to be used, secure the short and long brackets to each side of the drawer as shown in Fig. 2. -
Page 8: Connect Extra Device
Connect Extra Device On the front of the RACKMUX-VS17-T is an additional USB Type A port to be used, if desired, for an extra accessory. Any low or full speed USB device may be connected to this port to be used. -
Page 9: Connect Power
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Connect Power Connect the IEC power cord to the power port as shown below. REAR VIEW OF RACKMUX-VS17-T NETWORK TECHNOLOGIES INCORPORATED 1275 Danner Dr Tel:330-562-7070 Aurora, OH 44202 Fax:330-562-1999 www.networktechinc.com... -
Page 10: Display Functions
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE DISPLAY FUNCTIONS Standard Controls The RACKMUX has 5 standard control buttons and a power LED. The 5 standard control buttons operate as follows: The Power button turns the RACKMUX LCD and backlight ON and OFF as desired. -
Page 11: Brightness/Contrast Menu
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Selection Purpose Range Setup Control OSD image position on screen • 10 to 60 seconds Set time OSD will stay on screen before auto shutoff • Several languages (see page 8) Select the language of the OSD menu •... -
Page 12: Setup Menu
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Setup Menu Selecting the Setup menu will bring up a screen in which the user can adjust the following: OSD POSITION - the position of the OSD menus on the LCD display... -
Page 13: Brightness/Contrast Menu
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Brightness/Contrast Menu Selecting the Brightness/Contrast menu will bring up a screen in which the user can adjust the brightness and contrast levels of the LCD display. Using the Up or Down arrows to navigate the menu, highlight either the BRIGHTNESS or CONTRAST sections and press the Select button to choose the option to adjust. -
Page 14: Keyboard Functions
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE KEYBOARD FUNCTIONS The main keyboard on the RACKMUX-VS17-T is a standard condensed Windows format. To reduce the keyboard size, some keys have been assigned multiple functions, accessible via the "Fn" key. -
Page 15: Number Pad
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Number Pad The functionality of a Number Pad on a standard Windows keyboard has been incorporated into this keyboard. To substitute the keys of the Number Pad The functionality of a Number Pad on a standard Windows keyboard has been incorporated into the keyboard of the RACKMUX-VS17-T (see Fig. -
Page 16: Other Functions Of The "Fn" Key
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Other Functions of the "Fn" Key The Function ("Fn") key (page11) will enable other standard keyboard features in addition to the Number Pad keys (page 12) . Key Function when Fn key is Key Function when Fn key is not locked ("Fn"... -
Page 17: Numeric Keypad Option
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Numeric Keypad Option Models with the Numeric Keypad option (-N) (i.e. RACKMUX-VS17-TN) have a standard Windows keyboard with 17-key numeric keypad. Note: The “Fn” key is not an active key on this keyboard. -
Page 18: Safety
This NTI product has been designed and fully tested with user safety of the utmost importance. As with all electronic devices, this NTI product should be handled and operated with care. In order to avoid possible injury and to reduce any risk of damage to this product, please read and follow each of these safety instructions. -
Page 19: Rackmux-Vs17 Drawer Standard Specifications
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE RACKMUX-VS17 DRAWER STANDARD SPECIFICATIONS General Specs Case Material..........Electro-galvanized steel black powdercoated Dimensions WxDxH (in.).......19 x 21.9 x 1.75 Supported Rack Depths………………………..Adjustable 22” – 39” Weight……………………………………………26 lbs. Input Power............AC 100-240V, 50 or 60 Hz LCD (plus controller) Current Draw…………..12V Supply: 3.75A... -
Page 20: Keyboard
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Keyboard No. Of Keys ...........83 Keys (US), 84 keys (UK,German, French, Italian, Spanish)+ 14 Sun keys Key Switch Type ..........Membrane switch Keytop Style...........Rectangular Cylindrical Operating Force ..........50gf +/- 25gf Stroke ............3.0mm +/- .5mm... -
Page 21: Troubleshooting
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
