NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH

3. USING THE SERIMUX CONSOLE SWITCH

The SERIMUX Console Switch is controlled using the TERMINAL and menu-driven integrated software.
The SERIMUX can be easily configured using the TERMINAL with a keyboard-controlled menu to modify various parameters and
options for each port to be connected to a device. The administrator menu can be accessed by the administrator for full feature
control, or the user menu, by any user, for more restricted control of port connections.
The SERIMUX supports 2 operator levels, administrator and user, each with separate password protection for security.
• The administrator logs in using an administrator password (see next page for login procedure)
administrator name :
administrator password : [nti] (all lowercase letters)
• Users login using a password set by the administrator
FYI: Users may be granted administrative access rights by the administrator.
Note: For units with a Serial Console/Switch firmware version prior to
v.1.11 (as seen in Fig. 7), the default administrator name is "ROOT" or
"ADMINISTRATOR" (all uppercase letters) and the default password is
"NTI" (all uppercase letters).
The administrator and any user with administrative rights is able to:
• view / modify port parameters;
• view / modify user parameters and user access rights to ports;
• disconnect ports, logout users etc.
• connect to host ports
[root] (all lowercase letters)
11
The administrator name cannot be
changed.
To change the administrator
password, see page 23.
