NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH

INTRODUCTION

The RACKMUX-T15-CS16 Rackmount Console Terminal Drawer with 16 port Console Switch (RACKMUX) places a VT100/ANSI
Terminal and a Console Switch right in the rack for space-saving, convenient control of SUN or PC-based headless servers,
routers, and firewalls. The LCD monitor terminal drawer eliminates the need for an external laptop or table-top dumb terminal.
The Console Switch delivers control of up to 16 serial devices via Ethernet, LAN or dial-up modem connections. It enables
unlimited access to remote network management, providing optimum system performance and availability.
Optional:
•
RACKMUX-T15-CS8 Rackmount Console Terminal Drawer with 8 port Console Switch
•
Anti-glare protective glass for the LCD- Add G to the model number (i.e. RACKMUX-T15G-CS16)
•
RL-T15-TEL- Mounting bracket for 2-post style Telco Rack
•
Numeric keypad- for a separate 17-key numeric keypad, add "-N" to the part number (i.e. RACKMUX-T15-N-CS16)

Console Terminal

The Console Terminal (TERMINAL) is easy to install and configure for either of the following communication modes:
RS232 Terminal (using an RS-232 port for serial console connection). Use this configuration of the Console Terminal with
the Console Switch to control multiple servers.
Telnet Terminal (using an RJ45 10/100 Base-T network port for Ethernet telnet console connection). The Ethernet
connection can be used with any 10/100Mbps-compatible Ethernet host adapter, but is most suited for use with SUN RSC
(Remote System Control) Ethernet ports, since these provide the same functionality as serial (ttya) console ports. This
connection supports up to 12 telnet sessions to different servers. The state of each server session is preserved by the
terminal. Terminal sessions can be switched via hot-keys. When using the Ethernet telnet connection, the Terminal Drawer
can be connected to multiple servers via an Ethernet switch. However, it is advisable that the network used to connect the
server consoles remains private for security reasons.
Note: Both RS232 serial and Ethernet telnet connections cannot be active at the same time.
The TERMINAL is a general purpose character terminal drawer offering full transaction capabilities and is largely pre-configured
for most applications. It was designed in conjunction with SUN Microsystems to ensure flawless compatibility with all SUN servers.
It is also compatible with most racks, including the Sun StorEdge 72", Sun Fire, and most EIA 19" racks. This console drawer is
the ideal solution for controlling web servers, DNS servers, mail servers and other equipment that lack video card capability, such
as the SUN Netra systems and HP servers.
Features
•
Entire unit is only 1U (1.75") high.
•
High-quality metal construction (ideal for most industrial and commercial settings)
•
15" TFT Rack Mount LCD Monitor features a wide viewing angle.
•
Screen size: 80x24 characters plus status line.
•
Keyboard lock prevents unauthorized use
•
800x600 resolution.
•
LCD Display controls (using on-screen menu).
•
83-key keyboard.
•
Supports RSC capabilities.
•
Serial and parallel slave-printer ports.
•
Includes rack mount kit suitable for SUN and most EIA 19" racks
•
Fits 22" to 36" rack depths via adjustable mounting brackets.
•
Connects to 10BaseT Ethernet port
Multiple RS-232 Emulations:
•
ADDS A2
•
PC TERM
•
PCG Alpha
•
Console ANSI
•
TVI910+
Compatibility
•
Compatible with any SUN or PC-based headless server.
•
Communicates with routers, bridges, firewalls, and hubs
•
TV1925
•
VT52
•
VT100
•
VT220
•
WY-50+
1
•
WY-60
•
WY-100
•
WY-120
•
WY-325
