Reference Information, cont'd
13.
14.

Button Labels

Eight sets of button labels are provided on the next page. Feel free to cut them out
of the manual, write the applicable button information in each button area, and
place them in the switcher's label window.
B-8 Integration Scaling Matrix Switcher • Reference Information
Secure the cover in place with the screws that were removed in steps 3 and 4.
Rack mount the switcher if desired and reconnect all cables.
