Icom ID-5100A Basic Manual page 85

During RX/Standby
During TX
One-Touch PTT(Remote MIC)
PTT Lock
Busy Lockout
Time-Out Timer
Active Band
MIC Gain
Touch Operation (Sub)
Keyboard Type
Data Speed
CI-V
CI-V Address
CI-V Baud Rate
CI-V Transceive
CI-V Bluetooth➝REMOTE
transceive Address
The default value may differ, depending on the transceiver version.
*
[UP]:UP [DN]:DOWN
[UP]:--- [DN]:---
OFF or ON
OFF or ON
OFF or ON
OFF, 1min, 3min, 5min, 10min,
15min or 30min
Single or All
1~2*~4
Main Select or Function Select
Ten-key, Full keyboard
4800bps or 9600bps
01h~8Ch~DFh
4800, 9600, 19200 or Auto
OFF or ON
00h~DFh
MENU SCREEN
Selects the key function to be used while receiving or
in the standby mode.
Selects the key function to be used while transmit-
ting.
Turns the One-Touch PTT function ON or OFF.
Turns the PTT Lock function ON or OFF.
Turns the Busy Lockout function ON or OFF.
Selects the Time-Out Timer time options.
Allows continuous frequency selection across all
bands by rotating [DIAL].
Sets the microphone sensitivity to suit your prefer-
ence.
Sets the touch operation on the SUB band display.
Selects the keyboard input type to enter a call sign,
memory name, and so on.
Selects the data transmission speed for low-speed
communication, or between the [DATA] jack and ex-
ternal modules like a GPS receiver, and so on.
Sets the transceiver's unique CI-V hexadecimal ad-
dress code.
Sets the CI-V code transfer speed.
Turns the CI-V Transceive function ON or OFF.
Sets the address to inhibit the external control with
CI-V for the transceiver through the [SP2] (REMOTE)
jack.
7
7
72
