7
MENU SCREEN
Menu items and Default settings (Continued)
■
TX Format
Position
Symbol
SSID
Comment
Time Stamp
Altitude
Data Extension
Power
Height
Gain
Directivity
Object
Object Name
Data Type
Symbol
Comment
Position
Data Extension
Course
Speed
The unit may differ, depending on the "Display Unit" settings. (p. 74)
*
65
1:Car, 2:Van, 3:Truck or 4:House QTH (VHF) Selects a desired D-PRS Symbol to transmit.
- - -, (-0), -1~-15 or -A~-Z
OFF, DHM or HMS
OFF or ON
OFF, Course/Speed or
Power/Height/Gain/Directivity
0W, 1W, 4W, 9W, 16W, 25W, 36W,
49W, 64W or 81W
10ft, 20ft, 40ft, 80ft, 160ft, 320ft,
640ft, 1280ft, 2560ft, 5120ft*
0dB~9dB
Omni, 45°NE, 90°E, 135°SE, 180°S,
225°SW, 270°W, 315°NW, 360°N
Live Object, Killed Object
Radio
OFF, Course/Speed or
Power/Height/Gain/Directivity
0°~360°
0mph~1150mph*
Selects the APRS ® call sign SSID.
Enters a comment to transmit.
Selects a format to transmit the current UTC time as
a time stamp.
Turns the altitude transmit option ON or OFF.
Selects whether to transmit the course/speed data,
power/height/gain/directivity data or not.
Selects the TX power level information to send when
using as a base station.
Selects the height information to send when using as
a base station.
Selects the antenna gain information to send when
using as a base station.
Selects the antenna directivity information to send
when using as a base station.
Enters a object station name to transmit.
Selects a object station's status to transmit.
Selects a object station's symbol to transmit.
Enters a object station's comment to transmit.
Sets a object station's position data to transmit.
Selects whether to transmit the object station's course/
speed data, power/height/gain/directivity data or not.
Sets a object station's course to transmit.
Sets a object station's speed to transmit.
