7
MENU SCREEN
Menu items and Default settings (Continued)
■
Directivity
SSID
Weather
Symbol
SSID
Comment
Time Stamp
NMEA
GPS Sentence
GPS Message
GPS Information
GPS Position
GPS Memory
GPS Alarm
Alarm Select
Alarm Area (Group)
Alarm Area (RX/Memory)
GPS Logger*
GPS Logger
Record Interval
*
Be sure to insert the SD card into the transceiver before selecting these items.
67
Omni, 45°NE, 90°E, 135°SE, 180°S,
225°SW, 270°W, 315°NW, 360°N
- - -, (-0), -1~-15 or -A~-Z
WX Station
- - -, (-0), -1~-15 or -A~-Z
OFF, DHM or HMS
RMC, GGA, GLL, VTG, GSA or GSV Transmits position data in selected GPS sentences.
(No Group), A~Z
OFF, RX, Group or Memory
0'05"/0.08'~0'15"/0.25'~
59'59"/59.99'
Limited, Extended or Both
OFF or ON
1sec, 5sec, 10sec, 30sec or 60sec
Selects the antenna directivity of the item station to
transmit.
Selects the APRS ® call sign SSID for the item sta-
tion.
Selects a weather station's symbol to transmit.
Selects the APRS ® call sign SSID for the weather
station.
Enters a weather station's comment to transmit.
Selects a format to transmit the current UTC time as
a time stamp.
Enter a GPS message to be transmitted.
Displays the received GPS information.
Displays your position, RX station, GPS memory and
Alarm positions.
Shows the GPS memory contents.
Select the target for the GPS alarm function.
Enter the GPS alarm active range.
Select the GPS alarm active range.
Turns the GPS logger function ON or OFF, to store
your route as you move.
Selects the GPS Logger function record interval.
