AV8OR User's Guide
Icon
Sky view
circle
Coordinates
n/a
n/a Status bar for the
satellites

Find menu

Select the destination of your route. Tap the following soft Keys:
Pub. No D200803000008
© Honeywell International Inc. Do not copy without express permission of
Color
Page 4-91
Honeywell.
Automotive Mode Operation
Name
The virtual sky
shows the visible
part of the sky
above you, with
your position as the
center. The
satellites are
shown at their
current positions.
The GPS receives
data from both the
green and yellow
satellites. Signals
from the yellow
satellites are only
received, while
green ones are
used by the GPS to
calculate your
current location.
Your current GPS
position in WGS84
format.
Dark bars are for the
yellow and lit bars
are for the green
satellites. The more
satellites your GPS
tracks (the green
ones), the better is
your calculated
position.
Revision July 2008.
Description
