Quick Reference

KLN 89(B) Pages
Airport (APT) Pages
1 Ident, elevation, name, city,
state, use type
2 Latitude/longitude, bearing/radial
and distance
3 Time from UTC, fuel, approaches,
radar environment
4 Runway numbers, length, surface,
lighting
5 Comm frequencies
6 User remarks
7 SID/STAR procedures
8 Non-precision approach procedures
VOR Pages
1 Ident, frequency, name, lat/long
2 Magnetic station declination,
bearing/distance
NDB Pages
1
Ident, frequency, name, lat/long
2
Bearing/distance
Intersection (INT) Pages
1
Ident, lat/long, bearing/distance
2
Location relative to VOR
User-defined Waypoint (USR) Pages
1
Ident, lat/long, bearing/distance
2
Location relative to VOR
Active Waypoint (ACT) Pages
Waypoint pages for active flight plan
waypoints and/or the direct-to waypoint
Navigation (NAV) Pages
1
Active waypoint/leg, CDI, DTK, TK,
bearing, ETE
2
Present position (lat/long or radial/
distance)
3
Present time, departure time, ETA at
destination, elapsed flight time
4
Moving map
Flight Plan (FPL) Pages
0
Active flight plan
1-25 Stored (numbered) flight plans
KLN 89/89B

GPS Navigation System

Calculator (CAL) Pages
1
Trip calcs for distance, bearing,
ESA, and ETE
2
Trip calcs for fuel requirements
3
Alarm/timer
4
Pressure altitude
5
Density altitude
6
True airspeed (TAS)
7
Winds aloft
8
Sunrise/sunset
Setup (SET) Pages
1
Position initialization for GPS
receiver
2
Date, time, and time zone
initialization
3
Data base update
4
Turn anticipation enable/disable
5
Default first waypoint character
6
Nearest airport criteria
7
SUA alert enable/disable
8
Barometric pressure units
9
Altitude alerting
10
Low voltage warning
11
Display brightness
Other (OTH) Pages
1
GPS state, GPS altitude, EPE
2
GPS signal status
3
RAIM prediction
4
List of user-defined waypoints
5
List of airports and user waypoints
with stored remarks
6
Software versions
7* Fuel required, on board
8* Fuel endurance, range, efficiency
9* Fuel flow
10* Cumulative fuel used
11* TAS, Mach
12* SAT, TAT, pressure alt, density alt
* Page only displayed if appropriate equip-
ment is interfaced with KLN 89(B)
-1-
