AV8OR User's Guide
FIG DISPLAY OR
NO CONTROL
1 Touch screen
2 POWER key
3 MENU key
4 LED charging status
indicator
5 SD slot and SD card
6 LOCK tab
7 6 VDC power
connector
8 Microphone
9 USB/Serial port
Pub. No D200803000008
© Honeywell International Inc. Do not copy without express permission of
DESCRIPTION
4.3 inch TFT touch screen.
The resolution is 480 x 272
pixels.
The POWER key is used to
turn the unit on and off and
also can put the unit into
Sleep mode and wake the unit
from Sleep mode.
The MENU key returns the
user to the main menu from
any program in the unit.
Shows the status of the
charging system while the unit
is being charged.
The SD slot holds a SD card
which contains the aviation
and automotive navigation
software.
The LOCK tab disables all
controls and stops the touch
screen from responding to
taps.
This connector lets the unit
receive power from an AC or
an automotive DC.
The microphone is used for
Bluetooth connections to cell
phones.
This is used for standard USB
connection to a PC to
download movies, pictures, E-
books and new updates to the
navigational software. Also
used for RS 232 connection to
external hardware with special
Page 2-2 Revision July 2008.
Honeywell.
Getting Started
