Choosing A Suitable Location - Compuprint 914 User Manual

Chapter 2

Choosing a Suitable Location

Consider the following points when you choose the location for your printer:
The distance between the printer and the host computer must not exceed
the length of the interface cable;
The location must be sturdy, horizontal and stable;
Your printer must not be exposed to direct sunlight, extreme heat, cold, dust
or humidity (see "Printer Specifications", in chapter 1);
You need an AC power outlet compatible with the plug of the printer's
power cord. The voltage of the outlet must match the voltage shown on the
printer's Name Plate;
Additionally, you must make sure that when you install the printer in the
selected location, there are sufficient clearances on all sides for easy operation.
The required space is shown below (unit: mm (inch)):
2.2
20 (0.79)
428 (16.85)
A78401745-001
