The following table shows you the 24 needles dot graphics modes available on
your printer (EPSON LQ and IBM Proprinter XL24 AGM modes):
m
32
33
38
39
40
ESC [ g {l} {h} {m}{n1}...{nk}
This command selects dot graphics in 8 or 24 needle configuration. {h}*256+{l}
represents the {number of data + l}. The {m} parameter represents the dot graphics
modes as shown in the following table:
m Density
0 60
1 120
2 120
3 240
8 60
9 120
Mode
Normal density
Dual density
Dual speed, dual density
Quadruple density
CRT Graphics I
CRT Graphics II
Mode
Single density
Double density
CRT Graphics III
Triple density
Hex density
Selects 8 or 24 needle dot graphics mode (only IBM
mode).
1B 5B 67 {l} {h} {m} {n1}...{nk}
27 91 103 {l} {h} {m} {n1}...{nk}
Needle
8
8
8
8
24
24
A78401745-001
dpi
60
120
120 (virtual)
240 (virtual)
80
90
dpi
60
120
90
180
360 (virtual)
Function
Same as ESC K (8 needles)
Same as ESC L (8 needles)
Same as ESC Y (8 needles)
Same as ESC Z (8 needles)
High Resolution for ESC K
High Resolution for ESC L
