Chapter 3

General Overview

The operator panel enables you to perform many of the printer functions
including pitch, font and printer setup selection. The operator panel is located in
the front side of the printer and appears as follows:
The operator panel consists of :
a 16- character display (Liquid Crystal Display)
shows various message usually regarding to the printing functions
nine indicators
report basic information about the printer's condition The indicators
light up green
seven function keys
allow you to change the operating state of the printer

Display Messages

The display messages can be divided into three main groups:
STATUS MESSAGES:
SETUP MESSAGES:
ERROR MESSAGES:
3.2
Provide information about operating state of the printer.
Display during the Printer Setup procedure.
Signal any printer faults. See "Error Messages
Description" in chapter 4.
