Chapter 2
4.
The tractor pull tractor unit
can be easily removed by
pressing it rearward.
Adjusting The Gap Between The Print Head And
Platen
Adjusting the gap between the print head and platen allows the optimum print
quality. The gap set lever is located at the right front side of the printer. When the
gap set lever is moved forward, the gap becomes wider. When it is moved
backward, the gap becomes narrower. Before printing, select the gap set lever
position as follows:
Position 1 :
Position 2 :
Position 3 :
Position 4 :
Position 5 or 6:
Position 6 :
2.8
1 sheet of paper
2 - 3 sheets of paper
3 - 4 sheets of paper
3 - 4 sheets of paper
Envelopes
Installing/removing the ribbon cartridge
