AT530P User Manual
Notice: AT530P supports three message maximum, each message can be 90 seconds. Answering will
be deactivated if the message numbers is 3.
Record local message:
User may use local message to leave message to other local users.
Please refer the Record button function as below:
Level1 Level2
Received
New
Old
Record
Playing
Local
Play
Rec
User define
Switch
Play
Rec

9.1.8 How to use set the IP type via keypad?

In the idle mode, user may us the keypad to set the IP type as the below procedure:
Keep pressing the button 1 for changing to static mode.
Keep pressing the button 2 for changing to DHCP mode.
Keep pressing the button 3 for changing to PPPoE mode.

9.1.9 VLAN implement

AT530P support rich 802.1Q/P protocol and Diffserv configuration. Through its flexible
VLAN function, you can set the voice/signaling and data packets in different VLAN via
different VLAN id.
Different implement of VLAN function:
1: if "Data/Voice VLAN differentiated" is undifferentiated. Device will set the same
vlan ID for voice and data. As show below
Record Function
Description
New message info
Old message info
Enable/disable answering machine
Enable/disable Incoming Record Playing
Play local message
Record local message
Enable/disable customize greeting message
Play customize greeting message
Record customize greeting message
46/49
