AT530P User Manual
Show current DHCP rules
Show LAN port IP address
Show NAT info
Change LAN port IP address
Example:<config-interface-fastethernet-lan>#ip –addr 192.168.1.10 –mask 255.255.255.0
WAN interface settings
path: <config-interface-fastethernet-wan>#
[disable]enable dhcp client
[disable]enable pppoe
[disable]enable QOS
Set default gateway IP
Clear default gateway IP
Set WAN port IP address
Example:<config-interface-fastethernet-wan>#ip
255.255.255.0
You need to reconnect if the WAN port has been changed.
Show WAN port settings
MMI Filter
path: <config-mmifilter>#
add filter rule
Example:<config-mmifilter>#entry –start 202.112.20.1 –end 202.112.20.255
Delete filter rule
Example:<config-mmifilter>#no entry –start 202.112.20.1
Show filter rule
[disable]enable MMI filter
NAT settings
path: <config-nat>#
[disable]enable ftp alg
[disable]enable ipsec alg
[disable]enable pptp alg
Add TCP mapping rule
Example:<config-nat>#tcp-entry –ip 192.168.1.5 –lanport 1720 –wanport 1000
Delete TCP mapping rule
Example:<config-nat>#no tcp-entry –ip 192.168.1.5 –lanport 5060 –wanport 1000
Add UDP mapping rule
Delete UDP mapping rule
Show NAT info
Netservice
path: <config-netservice>#
Set DNS address
Example:<config-netservice>#dns –ip 202.112.10.36 _domain voip.com
Set alternate DNS address
Set hostname
Set http access port
Show http access setting
Set telnet access port
Show telnet access port
Set RTP initial port and quantity
Example:<config-netservice>#media-port –startport 10000 –number 200
Add route rule
Example:Arcihfone<config-netservice>#route –gateway 202.112.10.1 –addr 202.112.210.1
–mask 255.255.255.0
Delete route rule
---dhcpshow
---ipshow
---natshow
---ip –addr x.x.x.x –mask x.x.x.x
---[no]dhcp
---[no]pppoe
---[no]qos
---gateway x.x.x.x
---no gateway
---ip –address x.x.x.x -mask x.x.x.x
---show
---entry –start x.x.x.x –end x.x.x.x
---no entry –start x.x.x.x
---show
---[no]start-filter
---[no]ftpalg
---[no]ipsecalg
---[no]pptpalg
---tcp-entry –ip x.x.x.x –lanport xxx –wanport xxx
---no entry –ip x.x.x.x –lanport xxx –wanport xxx
---udp-entry –ip x.x.x.x –lanport xxx –wanport xxx
---no udp-entry –ip x.x.x.x –lanport xxx –wanport xxx
---show
---dns -ip x.x.x.x _domain xxx
---alterdns -ip x.x.x.x _domain xxx
---hostname xxx
---http-port xxx
---http-port
---telnet-port xxx
---telnet-port
---media-port –startport xxx –number xxxx
---route –gateway x.x.x.x –addr x.x.x.x –mask x.x.x.x
---no route –gateway x.x.x.x –addr x.x.x.x –mask x.x.x.x
–addr 202.112.241.100 –mask
