xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
Example
To display the GVRP status of the switch:
DGS-3620-28SC:admin#show gvrp
Command: show gvrp
Global GVRP : Disabled
Join Time : 200 Milliseconds
Leave Time : 600 Milliseconds
LeaveAll Time : 10000 Milliseconds
NNI BPDU Address: dot1d
DGS-3620-28SC:admin#
113-16 config private_vlan
Description
A private VLAN is comprised of a primary VLAN, up to one isolated VLAN, and a number of
community VLANs. A private VLAN ID is presented by the VLAN ID of the primary VLAN. The
command used to associate or de-associate a secondary VLAN with a primary VLAN. A primary
VLAN is created via the command create vlan type private_vlan. A secondary VLAN is created
via the command create vlan type 1q_vlan. A secondary VLAN cannot be associated with
multiple primary VLANs. The untagged member port of the primary VLAN is named as the
promiscuous port. The tagged member port of the primary VLAN is named as the trunk port. A
promiscuous port of a private VLAN cannot be promiscuous port of other private VLANs. The
primary VLAN member port cannot be a secondary VLAN member at the same time, or vice versa.
A secondary VLAN can only have the untagged member port. The member port of a secondary
VLAN cannot be member port of other secondary VLAN at the same time. When a VLAN is
associated with a primary VLAN as the secondary VLAN, the promiscuous port of the primary
VLAN will behave as the untagged member of the secondary VLAN, and the trunk port of the
primary VLAN will behave as the tagged member of the secondary VLAN. A secondary VLAN
cannot be specified with advertisement. Only the primary VLAN can be configured as a layer 3
interface. The private VLAN member port cannot be configured with the traffic segmentation
function.
Format
config private_vlan [<vlan_name 32> | vid <vlanid 1-4094>] [add [isolated | community] |
remove] [<vlan_name 32> | vlanid <vidlist>]
Parameters
<vlan_name 32> - Enter the name of the private VLAN. The maximum length is 32 characters.
vid - Specifies the VLAN ID of the private VLAN.
<vlanid 1-4094> - Enter the VLAN ID between 1 and 4094.
add - Specifies to add isolated or community.
isolated - Specifies the secondary VLAN as an isolated VLAN.
community - Specifies the secondary VLAN as a community VLAN.
remove - Specifies to remove the specified private VLAN.
<vlan_name 32> - Enter the VLAN of a range of secondary VLANs to add to the private VLAN or
remove from it. The maximum length is 32 characters.
vlanid - Specifies a range of the second VLAN IDs to add to the private VLAN or remove from it.
