Please Note: On a daisy chained installation, connect the cable to the
First Station (Master) unit. The chained stations (Slaves) will receive the
upgrade via the daisy chain cables.
1.
Shut down all of the computers - but not the Stations - on your KVM
installation.
2.
From your KVM switch console, bring up the OSD and select the
F4ADM function.
3.
Scroll down to FIRMWARE UPGRADE. Press
to invoke Firmware Upgrade Mode. For your reference, the current
firmware upgrade version displays on the screen.
Performing the Upgrade
Starting the Upgrade
To upgrade your firmware:
1.
Run the downloaded Firmware Upgrade Package file - either by double
clicking the file icon, or by opening a command line and keying in its
location.
2.
When the Firmware Upgrade Utility Welcome screen appears, please
review the License Agreement, enable the I Agree radio button, and
click on Next.
3.
The Firmware Upgrade Utility main
screen will appear and inspect
your installation. All of the devices
capable of being upgraded by the
downloaded package will be listed in
the Device List panel. Highlight
the devices you wish to upgrade and
click on Next.
4.
If you enabled Check Firmware
Version, the Utility compares the
device's firmware level with that of the upgrade files. If it finds that the
version already installed is higher than the upgrade version, it brings
up a dialog box informing you of the situation and gives you the option
to Continue or Cancel.
Instruction Manual
35
[Enter], then press [Y]
Select the
appropriate
device(s) here
