StarTech.com C2-DD46-UA2-CBL-KVM Quick Start Manual

2-Port Dual Monitor Cable KVM Switch - DisplayPort - 4K 60Hz
Product ID
C2-DD46-UA2-CBL-KVM
Top
1
Sides
9
Front
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
10
11
12
Component
1
LED Indicators
2
2 PC 1 Audio Connectors
3
PC 1 USB-A Host
3
Connector
4
PC 1 DisplayPort
4
Connectors
5
5
Remote Port Selector
PC 2 DisplayPort
6
6
Connectors
PC 2 USB-A Host
7
Connector
7
8 PC 2 Audio Connectors
8
Console Microphone
9
Port
10 Console Audio Output
Console DisplayPort
11
Output Ports
12 Console USB HID Ports
Product Information
For the latest manuals, product information, technical specifications, and declarations of
www.StarTech.com/C2-DD46-UA2-CBL-KVM
conformance, please visit:
Package Contents
• KVM Switch x 1
• Quick-Start Guide x 1
Quick-Start Guide
Function
• Solid Green = Selected PC is Connected
• Blinking Green = Selected PC is not detected
• Amber LED = Selected Audio Source
• Green: Connect to 3.5mm Headphone Port
• Pink: Connect to a 3.5mm Microphone Port
• Connect to a USB-A port on PC 1
• Connect to a DisplayPort Enabled Computer
• A wired button used to switch between PC 1
and PC 2
• Press and Release the Remote Switch to switch
between PC 1 and PC 2
• Connect to a DisplayPort Enabled Computer
• Connect to a USB-A port on PC 2
• Green: Connect to 3.5mm Headphone Port
• Pink: Connect to a 3.5mm Microphone Port
• Pink: Connect a Microphone
• Green: Connect an Audio Device (ie. Speakers
or Headphones)
• Connect to two DisplayPort Displays
• Connect a USB Mouse and Keyboard
Manual Revision: January 17, 2023 2:00 PM
