OSD Navigation
•
To dismiss the menu, and deactivate the OSD, press
•
To Logout, press
•
To move up or down through the list one line at a time, use the
Down Arrow Keys. If there are more list entries than there is room for
on the Main Screen, the screen will scroll.
•
To bring the KVM focus to a port, move the Highlight Bar to it then
press [Enter]
•
After executing any action, you automatically go back to the menu one
level above
Heading
SN-PN
This column lists the Port ID numbers (Station Number - Port
Number) for all Computer Ports on the installation. The simplest
method to access a particular computer is to scroll to the desired
selection using the up and down arrow keys, then press Enter
QV
If a port has selected for Quick View scanning, an arrowhead will
be displayed in this column
The computers that are powered on and are On Line will be
indicated in this column with a Sun symbol
NAME
If a port has been given a name its name appears in this column.
OSD Main Screen Headings
OSD Functions
OSD functions are used to configure and control the OSD. For example,
rapidly switching to any port, scanning only selected ports, limiting the
list of ports you wish to view, designating a port as a Quick View Port,
managing port names or making OSD setting adjustments.
Instruction Manual
[F8]
Explanation
17
[Esc]
Up and
