To access an OSD function:
1.
Press a Function Key on the keyboard.
2.
In the Submenus that appear, make your choice by scrolling the
Highlight Bar to it, then pressing [Enter].
[Esc] to return to the previous menu level.
3.
Press
F1 GOTO
Pressing [F1] activates the GOTO function. GOTO allows you to switch
directly to a port either by keying in the port's Name, or its Port ID.
To use the Name method - key in 1, key in the port's Name; then press
[Enter]
To use the Port ID method - key in 2, key in the Port ID; then press
[Enter]
F2 LIST
This function allows you to broaden or narrow the scope of which ports
the OSD displays (lists) on the Main Screen. Many of the OSD functions
only operate on the computers currently selected for listing on the Main
Screen with this function. The submenu choices and their meanings are
given in the table below:
POWERED ON
QVIEW +
POWERED ON
Choice
ALL
QVIEW
Instruction Manual
Meaning
Lists all of the ports on the
installation
Lists only the ports that are
connected to powered computers
Lists only the ports that have been
selected as Quick View Ports
Lists only the ports that have been
selected as Quick View Ports and
that have their attached computers
powered on.
18
