7.1

Adding a Controller

The TX3 telephone access system may be integrated with other controllers, such
as the TX3-CX Card Access system and elevator restriction, through a peer-to-
peer connection via the RS-485 bus.
Note:
To integrate another controller
1.
2.
3.
4.
5.
6.
Telephone Access System Installation and Operation Manual
92 (112)
LT-969 Copyright 2012
Ensure that all network devices each have unique ID addresses.
Ensure the Telephone Access System and the controller are setup and
ready for operation.
Turn the power OFF for all units on the network.
Connect the controller to the Telephone Access System via the RS-485 bus
using the RS-485 connectors.
Turn the power ON for all units on the network.
Connect the PC to either the Telephone Access System or controller using
the USB port.
Use the TX3 Configurator Program to add and configure the controller to
the network.
Adding Controllers
Version 1.6
