1.3

Lobby Control Unit Enclosures

There are three sizes of enclosures for Lobby Control Units:
Universal Series. The Universal Series enclosure is an indoor/outdoor unit for
the scrolling Lobby Control Unit.
Universal Slim-Line Series. The Universal Slim-Line enclosure is an indoor/
outdoor unit that is narrower and longer than the Universal and Continental
series, and is for the scrolling Lobby Control Unit. This series is also available as
a kit.
Continental Series. The Continental Series is a stainless steel indoor unit larger
than the Universal Series and is for the scrolling Lobby Control Unit.
1.3.1 Universal Series
The Universal Series enclosures are surface or semi-flush mounted with the
Lobby Control Units. Optional flush trim rings are available for semi-flush and
flush installations. A rain hood is included allowing for outdoor use.
The following Universal Panel models use the Scrolling Directory:
Model TX3-120U. Stainless steel finish entry panel with speaker, microswitch
for postal lock, 200 name main controller board, 4x20 LCD display, 120 name
paper directory and one PS-4P transformer plug. Designed for outdoor
applications.
Model TX3-200-8U. Stainless steel finish entry panel with speaker,
microswitch for postal lock, 200 name main controller board, 8x20 LCD display
and one PS-4P transformer plug. Designed for outdoor applications.
Model TX3-1000-8U. Stainless steel finish entry panel with speaker,
microswitch for postal lock, 1000 name main controller board, 8x20 LCD display
and one PS-4P transformer plug. Designed for outdoor applications.
Model TX3-2000-8U. Stainless steel finish entry panel with speaker,
microswitch for postal lock, comes with a 2000 name main controller board,
8x20 LCD display and one PS-4P transformer plug. Designed for outdoor
applications.
1.3.2 Universal Slim-Line Series
The Universal Slim-Line series enclosure houses the following models and can
be surface or semi-flush mounted:
Model TX3-200-4U. Stainless steel finish slim-line entry panel with speaker,
microswitch for postal lock, 200 name main controller board, a 4x20 LCD
display and one PS-4P transformer plug. Designed for outdoor applications.
Model TX3-1000-4U. Stainless steel finish slim-line entry panel with speaker,
microswitch for postal lock, 1000 name main controller board, a 4x20 LCD
display and one PS-4P transformer plug. Designed for outdoor applications.
