Model TX3-2000-4U. Stainless steel finish slim-line entry panel with speaker,
microswitch for postal lock, 2000 name main controller board, a 4x20 LCD
display and one PS-4P transformer plug. Designed for outdoor applications.
1.3.3 Universal Slim-Line Kit
The Universal Slim-Line series is available as a kit:
Model TX3-NSL-12K. The TX3-NSL-12K kit consists of:
The Universal Panel Accessories consist of the following:
Model TX3-UFT. Universal Flush mounting trim for use with TX3-120U, TX3-
200-8U, TX3-1000-8U and TX3-2000-8U. Stainless steel.
Model TX3-USFT. Universal Slim-Line Flush mounting trim for TX3-200-4U.
Stainless steel.
1.3.4 Continental Series
The Continental Series enclosure for Lobby Control Units are flush mounted and
for indoor use only. The following Continental Series models use the Scrolling
Directory:
Model TX3-120C. Stainless steel finish Lobby Control Unit with speaker,
microswitch for postal lock, 120 name paper directory, flush mounting back box
and a PS-4P transformer plug. Designed for indoor use.
Model TX3-200-8C. Stainless steel finish Lobby Control Unit with speaker,
microswitch for postal lock, 200 name main controller board, 8x20 LCD display,
flush mounting back box and one PS-4P transformer plug. Designed for indoor
use.
Model TX3-1000-8C. Stainless steel finish Lobby Control Unit with speaker,
microswitch for postal lock, 1000 name main controller board, 8x20 LCD
display, flush mounting back box and one PS-4P transformer plug. Designed for
indoor use.
Version 1.6 Telephone Access System Installation and Operation Manual
LT-969 Copyright 2012
• TX3-200-4U slim-line entry panel with speaker and microswitch
for postal lock
• 4x20 LCD display
• PS-4P transformer plug
• TX3-NSL-8M Master NSL Relay Cabinet with one PS-4P
transformer plug
• 2012K Twelve Telephone Relay Kit with a 2012 Twelve Telephone
Relay board and a 9106 Cable
• RJ-71C Punch Down Block for outdoor applications
