6.3

Wiring the TX3-ER-8 Elevator Restriction Unit

The TX3-ER-8 Elevator Restriction Backplane use a ribbon cable to connect to
the Elevator Restriction Main Controller board.
The TX3-ER-8 Elevator Restriction Controller has eight sockets for the 2012E
Relay Boards.
6.3.1 Elevator Controller Board
Figure 40 shows the general layout of the Elevator Controller board components.
TX3-ER-8 Elevator
Restriction Unit

Figure 40. Elevator Controller Board

Version 1.6 Telephone Access System Installation and Operation Manual
LT-969 Copyright 2012
Elevator Restriction Unit Installation and Configuration
P6
P5
SW2
8
1
JW3 JW4 JW2
JW1 JW5
USB
RS-485 Terminals
P4
R
Res.
T
R
Co.
T
R
T
P3
16V AC
IN
ON OFF
SW1
83 (112)
