Figure 24. Firmware Upgrade - Program New Firmware - Mircom TX3 Series Installation And Operation Manual

6.
7.
8.
9.
4.10.2 Firmware Version Control
The firmware version number is accessible from the configurator software and
changes whenever there is a major, minor or revision update.
The following convention is used whenever there is a major, minor or revision
change:
Initial release. Version 1.00.0
Major change. Version 2.00.0
Minor change. Version 2.01.0
Revision changes. Version 2.01.1
Version 1.6 Telephone Access System Installation and Operation Manual
LT-969 Copyright 2012
Complete the procedure and click Next. The Program new firmware
window appears.

Figure 24. Firmware Upgrade - Program new firmware

Click Send to download the firmware or Back to repeat the procedure.
Click Next to complete the upgrade and exit the session.
Disconnect the USB cable from the controller and re-activate.
Lobby Control Unit Setup
55 (112)
