Hayes ADSL Duo Modem User Manual page 58

Click Update and Save Configuration after each set of entries.
The active routes are displayed at the bottom of the page.
Under Dynamic Route Configuration, make these entries:
RIP Version Version 1 or Version 2. Routers transmit
information to and from other routers. RIP
Version 1 broadcasts the route to other routers
on the LAN and to the ISP's gateway via the
DSL line. Version 2 shares the route via a
multicast packet to the LAN and WAN.
Distribute If selected, shares the static route information
Static Routes as well as the dynamic routes that are normally
shared via RIP.
Under Static Route, make these entries:
Index A number 1-20 to identify the route.
Enable Makes the route active or inactive.
IP Address The gateway IP address to be used for the
route. Specify the netmask by appending /xx
to the address (for example, /24).
54 Hayes ADSL Duo User's Guide
