Step 4: Establishing Communication - Hayes ADSL Duo Modem User Manual

5 5 5 5
When the configuration process is done, you will see a
Completing the Internet Connection Wizard dialog box.
Windows 98/Me/2000 users: Be sure to uncheck the box that
says "To connect to the Internet immediately, select this
box...."
6 6 6 6
Click Finish.
7 7 7 7
Windows XP users: Close Control Panel.
Windows 98/Me/2000 users: If Internet Explorer is open,
close it.
Continue with Step 4, Establishing Communication.

Step 4: Establishing Communication

The final step in the installation is setting up your Internet
connection.
1 1 1 1
Windows users should have a Hayes icon on their desktop that
looks like this:
Click the icon to display the Hayes ADSL login page.
If you do not have an icon on your desktop like the one shown
above, open your Web browser, type http://10.0.0.2, and
press Enter (or Return) to display the login page.
If the login page doesn't display, perform the following in
this order: Recheck all connections; restart the modem and
computer; and reset the modem by inserting a paper clip into
the Reset pinhole and holding for five seconds.
In this manual we use the name Configuration Manager to
refer to the software reached by way of the Hayes icon or by
typing http://10.0.0.2 into your browser.
9
