Hayes ADSL Duo Modem User Manual page 43

VPI Supplied by your service provider.
VCI Supplied by your service provider.
Encapsulation LLC or VC. Supplied by your service
provider. See page 33.
IP Address The modem's static IP address specified by
your service provider.
Gateway The gateway's WAN IP address specified by
your service provider.
MTU (Maximum Transmission Unit) Value (in
bytes) of the largest packet to be sent.
Typically set to 1500.
Traffic Profile The index number 0-7 of a previously
configured profile defining the Quality of
Service. See page 56.
WAN IP Filter The index number 0-7 of a previously-
configured WAN IP filter. See page 44.
Default Route Selected is the default. See page 35.
RIP Mode (Routing Information Protocol Mode for the
WAN interface) The options are disabled (the
default), passive, or active. See page 35.
Virtual Circuit Accept the default, which is 0, or if you are
configuring an additional connection, select
another number. See page 35.
When you finish, click Update, then Save Configuration.
39
