If you cannot access Internet Explorer:
Windows XP users: From the desktop, click the Start button,
then click Control Panel. In Control Panel, click Network
and Internet Options and then click the Internet Options
icon.
Windows 98/Me/2000 users: From the desktop click the Start
button, point to Settings, and then click Control Panel. In
Control Panel, click the Internet Options icon.
2 2 2 2
In the Internet Properties dialog box, click the Connections
tab.
3 3 3 3
On the Connections tab, click Setup.
4 4 4 4
Windows XP users: In the Welcome to the New Connection
Wizard dialog box, click Next.
If you see a Location Information dialog box, click Cancel
to return to the Welcome dialog box, and click Next again.
In the Network Connection Type dialog box, click Connect
to the Internet.
In the Getting Ready dialog box, click "Set up my
connection manually," and then click Next.
In the Internet Connection dialog box, click "Connect using
a broadband connection that is always on," and click Next.
Windows 98/Me/2000 users: In the Internet Connection
Wizard dialog box, select "I want to set up my Internet
connection manually, or I want to connect through a local
area network (LAN)," and click Next.
In the Setting up your Internet connection dialog box,
change the selection to "I connect through a local area
network (LAN)" and click Next.
In the Local area network Internet configuration dialog
box, uncheck the box "Automatic discovery of proxy
server." Then click Next.
A dialog box asks if you want to set up an email account. Click
No and then Next.
8 Hayes ADSL Duo User's Guide
