these settings, it will make installation a little faster and easier,
but don't worry if you don't have them. We'll tell you how to
figure them out.
If Your Service Provider Gave You Protocol, VPI,
VCI, and Encapsulation Settings
1 1 1 1
If you have this information (Protocol, VPI, VCI, and
Encapsulation), select the correct Protocol from the list. The
screen may change slightly, depending on the protocol you
select.
2 2 2 2
Enter the VPI, VCI, and Encapsulation in the appropriate
boxes.
3 3 3 3
If you selected PPPoE as your Protocol, your provider may
also have given you a Service Name. If so, enter it in the
appropriate box. (This information is optional.)
4 4 4 4
If you selected PPPoE or PPPoA as your Protocol, your
provider should have given you a User ID or User Name
(usually your email address or the characters preceding the @
sign in your email address) and a Password. (These are NOT
the User ID and Password that you used to get into the Basic
Setup menu.) If you cannot remember or cannot find your
User ID and Password, call your service provider and say you
have misplaced your user name and password. Then enter
them as well. This information is required with PPPoE and
PPPoA protocols.
5 5 5 5
If you selected 1483 Bridged with Static IP or 1483 Routed
with Static IP as your Protocol, your provider should have
given you two series of numbers for the IP (Internet Protocol)
Address and Gateway. Enter these numbers in the
appropriate boxes.
6 6 6 6
Leave the Virtual Circuit box at 0.
7 7 7 7
Click Update, then Save Configuration.
8 8 8 8
Go to your Web browser (i.e., Internet Explorer or Netscape
Navigator) and try to connect to a familiar Web address.
9 9 9 9
If you connect successfully, your installation is complete
and you're ready to browse the web! If you do not connect
11
