Hayes ADSL Duo Modem User Manual page 55

Make the following entries:
Enable Lets you enable or disable a Type of Service
change.
Src IP Originating IP address in the IP packet header.
Address If this field is empty, the source IP address is
not used to filter the packets.
Dst IP Destination IP address in the IP packet header.
Address If this field is empty, the destination IP address
is not used to filter the packets.
Protocol If you select udp or tcp, you must specify a
port or a range of ports in the Ports field.
If you select all, the ADSL Duo matches
packets from both udp and tcp. The Ports field
is disabled.
Ports You can specify a single port number (for
example, 80) or a range of port numbers
separated by colons (for example, 80:100).
ToS Existing Type of Service. Options are:
New ToS New Type of Service. Options same as above.
Click Update and then Save Configuration.
Normal
Min (minimum) cost
Reliable (maximum reliability)
Throughput (maximum throughput)
Min (Minimum) delay
51
