  • Page 1 ® AVerMedia AVerDiGi EXR6008 User Manual...
  • Page 2 In no event will AVerMedia be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages.
  • Page 3 WARNING TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE CAUTION IF THERE IS ANY DAMAGE, SHORTAGE OR INAPPROPRIATE ITEM IN THE PACKAGE, PLEASE CONTACT WITH YOUR LOCAL DEALER. WARRANTY VOID FOR ANY UNAUTHORIZED PRODUCT MODIFICATION NOTICE - INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Introduction................1 Package Content....................1 Features and Specifications ................. 1 Front Panel......................2 Back Panel ......................5 Setting Up the DVR Unit..................6 1.5.1 Installing the Removable Hard Disk ..............6 1.5.2 Install Internal SATA Hard Disk ................ 8 1.5.3 Connecting Devices ..................
  • Page 5 Familiarizing the Remote Console Buttons............44 5.2.1 To Setup Remote Console Setting ..............45 Familiarizing the WebViewer PTZ Buttons ............46 Using the Remote Playback ................46 5.4.1 Familiarizing the Local Playback Buttons............48 5.4.1.1 To Cut and Save the Wanted Portion of the Recorded Video ..... 49 5.4.2 Familiarizing the RealTime Playback Buttons ..........

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction Package Content (1) EXR6008 unit (2) Remote Control (batteries included) (3) Quick Installation Guide (4) Power Cord * The power cord varies depending on the standard power outlet of the country where it is sold. (5) Software CD (User Manual included) (6) SATA cable (7) 12 * screws for HDD installation Features and Specifications...

  • Page 7: Front Panel

    Central Management System(CMS) supported Remote console supported Support network, playback, and recording simultaneously Full-screen resolution: 1024 x 768(VGA) / 720 x 480 (NTSC) / 720 x 576 (PAL) At D1 resolution, EXR can record 240/200fps It can support IP camera resolution up to 1600 x 1200 Scheduled recording (00:00~23:00 set by hour and week ) Search for recorded video files by date/time/event Support daylight saving and network time synchronize...
  • Page 8 Name Function Playback control button in playback mode Speed shuttle for adjusting reversed and forward (2x, 4x, 8x, 16x or 32x) speed during playback. Turn left is reversed and turn right is forwarded. To move to next or previous frame during playback. Turning left is to go back to one previous frame and turning right is to go forward one frame.
  • Page 9 Name Function (16) LCD Display Display DVR system status such as temperature and operate status As a number key for entering password in playback and preview mode Channel camera selection number in playback and preview mode (17) Number button With button can switch to different screen display modes As a preset position with...

  • Page 10: Back Panel

    Back Panel (10) (12) (2) (3)(4)(5) (11) Name Function VGA Out Output the video signal to a CRT or LCD monitor USB Port For connecting USB interface devices LAN Port For Gigabit Ethernet connection Audio Out Output the audio signal to audio output device The audio input device needs to be powered by external power.

  • Page 11: Setting Up The Dvr Unit

    → Pure For hard disk spec, please referring to http://www.avermedia.com/AVerDiGi/Product/ IP Cam Solutions → AVerDiGi EXR6008 → Hardware Recommendations The “compatible hard disks” indicated in the above recommendation list only means that these ® commercially available hard disks were tested with AVerMedia products and functioned well ®...
  • Page 12 Carefully insert the hard disk in the removable Turn the removable hard disk drawer over and rack screw hard disk with screws And then, close the removable hard disk drawer Slide the drawer back cover Lock the removable hard disk drawer keylock 10.

  • Page 13: Install Internal Sata Hard Disk

    1.5.2 Install Internal SATA Hard Disk User can install up to 3 SATA hard disks inside the DVR unit if it is necessary. Please follow the below steps to install the hard disk. 1. Loosen all screws and push the cover backward 2.
  • Page 14 7. Plug anther side of SATA cable into hard disk 8. Screw tight the hard disk rack inside the DVR unit 9. Push the cover forward and secure the cover...

  • Page 15: Connecting Devices

    1.5.3 Connecting Devices The back panel of the DVR unit, user can connect up to 8 IP cameras through the internet. The DVR unit also can connect 8 sensor devices, 8 alarm devices, and output video to a TV or CRT/LCD monitor.

  • Page 16: Sensor And Relay Pinhole Allocation

    Sensor and Relay pinhole allocation The Sensor and Alarm enable you to connect 8 sensor inputs and 8 relay outputs. Just connect the external sensor and relay pin directly to the pinhole. Check the table below and locate which pinhole is assigned to sensor input and relay output.

  • Page 17: Familiarizing The Remote Control Buttons

    Familiarizing the Remote Control Buttons Use the Remote control to operate the DVR unit. Name Function Switch to playback mode To reset alarm status To select the time and date of playback file Fast play the video playback at the speed of 2x, 4x, 8x, 16x or 32x Decrease the video playback at the speed of 1/2x or 1/4x...
  • Page 18 Name Function As a number key for entering password in playback and preview mode Channel camera selection number in playback and preview mode (15) As a preset position with in PTZ control mode With button can switch to different screen display modes and enable auto scan and full screen.

  • Page 19: Chapter 2 Using The Dvr Software

    Chapter 2 Using the DVR Software Way to Operate DVR There are three ways can be managed the DVR unit: Using mouse and keyboard Connecting the mouse and keyboard through USB interface, user can manage the DVR unit easily. For the first time using DVR unit, mouse and keyboard is the best way to set up all DVR relevant configurations.
  • Page 20 The hard disk must be formatted before user can use it with DVR unit. Following the below steps to format the hard disk. Click Setup and enter the password Click System → Add Select the hard disk from device list and select Format type Click Format button to start formatting When formatting is done, click OK.

  • Page 21: Familiarizing The Buttons In Preview Mode

    Familiarizing the Buttons in Preview Mode Cam02 Cam01 (15) Cam03 (14) (13) (12) Cam04 (11) (10) Cam05 Cam06 Cam07 Cam08 Name Function Reboot: To restart the DVR system. It is required to enter the password Exit Power Off: To shut down the DVR system. It is required to enter the password Login: Using different ID to login to DVR system.

  • Page 22: Familiarizing The Buttons In Ptz Camera Controller

    Name Function (12) Event log Show the record of activities that take place in the system. (see also Chapter 2.2.2) (13) AutoScan Start/Stop video screen cycle switch. (14) Full screen View in full screen. To return, press the right button of the mouse or ESC on the keyboard or click the arrow icon.

  • Page 23: Using Event Log Viewer

    2.2.2 Using Event Log Viewer Show the record of activities that take place in the system. 1. Click the Event Log button on DVR system main interface. The Event log viewer window will show up. 2. Select the Date to view. 3.

  • Page 24: Familiarizing The Buttons In Playback Mode

    Familiarizing the Buttons in Playback Mode To switch in Playback mode, click Playback button at the lower right corner of Preview mode user interface. Cam02 Cam01 Cam03 (12) Cam04 (11) (10) Cam05 Cam06 Cam07 Cam08 (4)(5) Name Function (1) Split Screen Select from 4 different split screen type to playback the recorded video file of all the Mode camera, or one camera over the other or alongside on a single screen.
  • Page 25 Name Function video file. (6) Preview Switch to Preview mode. (7) Playback Switch to Playback mode. This allows you to view the recorded video file. (8) Status bar Display the recorded date, time and play speed. (9) Camera ID Show the number of cameras that are being viewed. When you are in single screen mode, click the camera ID number to switch and view other camera.

  • Page 26: Chapter 3 Customizing The Dvr System

    Chapter 3 Customizing the DVR System In the Preview screen mode, click button to customize your DVR. When the DVR configuration setup selection appears, select and click the buttons you want to change the setting. System Setup In the System Setting dialog box, click OK to accept the new settings, click Cancel to exit without saving.
  • Page 27 (2) Delete recorded data after If you want the system to automatically erase the data after a certain days, enable the Delete recorded data after check box and enter the numbers of days in Days text box. (3) Delete event and alarm log after If you want the system to automatically erase the event and alarm log after a certain days, enable the Delete event and alarm log after check box and enter the numbers of days in Days text box.
  • Page 28 (10) Time Adjust the DVR system time and date. Click Setting to select the month, date, hour, and minute. Mark Daylight saving check box to enable daylight saving function. And then, select the Start and End Time by click Setting. Assign a time that it is for daylight saving time offset in your time zone. For example: if the time zone is in U.S.

  • Page 29: Camera Setup

    Camera Setup The DVR system supports 8 IP cameras. Cam01 (1) Camera Icons Select the camera number you want to view. To enable/disable all cameras, click ALL check box. (2) Enable Set to enable/disable the selected camera. When there is no video source on the camera, we suggest disabling it so that the system won’t detect it as video loss error.
  • Page 30 Click the radio button of Protocol to start setup IP camera. Select the Protocol, Model, Video Format, Resolution, and Channel of the IP camera. Enter IP address and connecting port in IP Camera Site column. Also, user can enter URL of IP camera instead of IP address. If the IP camera has authority request, please enable Authentication and enter ID and Password.

  • Page 31: Recording Setup

    Recording Setup (1) Camera Icons Select the camera number you want to set the recording setting. To select all the cameras, enable the ALL check box. To select more than one camera, Right click on the camera icon. To select one camera only, Left click on the camera icon.

  • Page 32: Network Setup

    Network Setup (1) Server Name Assign a name for the DVR unit. Alphabet letters and numbers only. (2) Transmitting Cameras Select and click on the camera number in the Transmitting Camera section you want to make it accessible via internet using WebViewer, Remote Console, PDA Viewer and JAVAViewer (still image).

  • Page 33: Backup Setup

    DHCP: Assign the IP address by local DHCP server to DVR system. PPPOE: Point-to-Point Protocol over Ethernet is a network protocol for encapsulating PPP frames in Ethernet frames. It is used mainly with ADSL services. If your network is using ADSL service connecting to internet, and then, select PPPOE mode.

  • Page 34: Playback Backup Video

    to shift the calendar to the left or right. 2. In the table below, click on the blue block to select the recorded file or click camera (01~08) or time (00~23) to select the whole row or column. The blue block turns red when it is selected. The block that appears in white doesn’t have data.
  • Page 35 Name Function (3) Hour Buttons Select and click to playback the recorded video file on the specific time frame. The Hour buttons represent the time in 24-hour clock. The blue bar on top of the hour button indicates that there is a recorded video file on that period of time. While the red bar indicates that you are currently viewing the recorded video file.

  • Page 36: To Search Using The Event Search

    Name Function (11) Segment Keep a portion of the recorded video (see also Chapter 3.5.1#(10)). (12) Full screen View in Playback-compact mode. To return, press the right button of the mouse or ESC on the keyboard or click the arrow icon. Click the arrow icon to escape from full screen display mode...

  • Page 37: To Search Using The Intelligent Search

    When the Event list appear, click and select the item you want to view. 3.5.3 To Search Using the Intelligent Search 1. Click on the video screen on where you want to search. 2. Click Intelligent Search. The Intelligent Search text (red) would appear at the lower left corner of the screen.

  • Page 38: Relay Setting

    Relay Setting The I/O device must be installed to use this function. 1. Click the drop-down list and select the relay ID number. 2. Enter relay name in Name column. 3. The system automatically detects the card and input number. In the Content section, enter Description of relay.

  • Page 39: Alarm Setting

    Alarm Setting In the Alarm Setting dialog box, click Add to insert and set new alarm setting, click Delete to remove the selected alarm setting, click OK to exit and save the setting, Cancel to exit without saving. 1. Click Add to insert and set a new alarm setting. Click the items in the (8) Alarm Setting List if you want to modify the alarm setting.
  • Page 40 b. Retrieve time: set the waiting duration before system switching back to original Preview mode. If the retrieve time is un-mark, the alarm video will keep enlarging until user switch back to Preview mode manually. The retrieve time range is 0~ 600 seconds. - Relay Output Set to enable/disable the relay operation when the alarm is activated and to extend additional time in...
  • Page 41 (1) Mail Server Enter the SMTP Server and port. If your e-mail system requires user identification, enable Authentication check box and enter ID and Password. (2) Mail Fill the mailing information. From: Enter the sender e-mail address. To and CC: Enter the recipient email address and separate it with comma or a semicolon (;).
  • Page 42 - Send to CMS (Central Management System) Enable/disable the selected camera to send video to CMS when the alarm is activated. Beside the Send to CMS check box, click Detail. In the CMS Setting, select the camera to enable/disable sending the video to CMS.

  • Page 43: User Setup

    User Setup Only superuser can access User Setting and change the password of SuperUser and User. Click OK to exit and accept the setting, and Cancel to exit without saving the setting.

  • Page 44: Chapter 4 Ienhance

    Chapter 4 iEnhance The bundled iEnhance is a video editing tool and can only be used with *.dvr video file. It allows you to adjust the video picture quality, segment and save the selected portion of the video, zoom in and out the image, and print or save the screen shot.

  • Page 45: To Use Istable

    Name Function (12) Noise Reduce Adjust the softness and repair the damaged colours. (13) Sharpness Improve the overall image by enhancing edges. This gives the image more depth. (14) Effects Gray Scale: convert the image into black and white (monochrome). Normalize: adjust the brightness intensity.

  • Page 46: Chapter 5 Using The Remote Programs

    Chapter 5 Using the Remote Programs User can use Microsoft Internet Explorer to access DVR system by entering the IP address. To use this feature, make sure that your PC and DVR server both are connected to the internet and the Network feature is enabled.

  • Page 47: Familiarizing The Webviewer Buttons

    Familiarizing the WebViewer Buttons Right-clicking on the WebViewer video screen, enables you to start video recording, change video quality, switch camera and enable/disable DirectDraw. (13) (12) (11) (10) Name Function (1) DirectDraw Enhance the video quality. Not all graphic cards can support this function. If you can not see the screen display correctly or screen is messed, please check with VGA card vendor.
  • Page 48 Name Function (13) Select cameras to Select to the view camera from different server. In Select Camera dialog box, view Display column, click to enable/disable viewing the camera. Click Add Server and select the server type between DVR and IP Cam to add.

  • Page 49: Familiarizing The Remote Console Buttons

    Familiarizing the Remote Console Buttons (16) (15) (14) (13) (12) (11) (10) Name Function (1) DirectDraw Enhance the video quality. Direct Draw function supports for certain VGA card. For more information, please contact your VGA card vendor. (2) Exit Close the Remote Console. (3) Audio button Enable/disable the sound.

  • Page 50: To Setup Remote Console Setting

    Name Function (16) Alarm Alert and display warning info. Superuser and user both can reset the alarm. 5.2.1 To Setup Remote Console Setting Click Setup button to call out the System Setting windows. Click OK to exit and save the setting and Cancel to exit without saving the setting.

  • Page 51: Familiarizing The Webviewer Ptz Buttons

    Familiarizing the WebViewer PTZ Buttons Name Function (1) Direction buttons Adjust and position the focal point of the PTZ camera. Click the center to pan automatically. (2) Zoom +/- Zoom in and out the image. (3) Select PTZ Choose to enable/disable the PTZ camera. In the Select PTZ dialog box, Select column, click to enable/disable viewing and controlling the PTZ camera.
  • Page 52 In the Video Playback Date/Time Selection, the number from 00 to 23 represent the time in 24-hour clock. The numbers from 01 to 8 represent the camera number. To Make a Selection: 1. Select the date in the calendar. Use buttons to shift the calendar to the left or right.

  • Page 53: Familiarizing The Local Playback Buttons

    5.4.1 Familiarizing the Local Playback Buttons (13) (12) (11) (10) Name Function Select from six (6) different split screen type to playback the recorded video (1) Split Screen Mode file of all the camera, or one camera over the other or alongside on a single screen.

  • Page 54: To Cut And Save The Wanted Portion Of The Recorded Video

    Name Function (8) Status bar Display the record date, time, HDD capacity in preview mode and play speed in playback mode. (9) Camera ID Show the number of cameras that are being viewed. When you are in single screen mode, click the camera ID number to switch and view other camera. (10) Output Save the segmented file in *.mpg, *.avi, or *.dvr format (see also Chapter...

  • Page 55: Familiarizing The Realtime Playback Buttons

    5.4.2 Familiarizing the RealTime Playback Buttons (11) (10) Name Function (1) Split Screen Mode Select from two (2) different split screen type to playback the recorded video file of all the camera, or one camera. - If there are only 8 cameras, you won’t be able to switch to 16, and 13 split screen mode. - To zoom in an area on the screen, Right click and Drag a square on the area you want to enlarge.

  • Page 56: Familiarizing The Download And Playback Buttons

    Name Function (11) Full screen View in Playback-compact mode. To return, press the right button of the mouse or ESC on the keyboard. When you switch to full screen in multiple-screen mode, Left click to toggle to only display one of the video in the multiple-screen mode or all. 5.4.3 Familiarizing the Download and Playback Buttons (11) (10)
  • Page 57 Name Function (6) Preview Switch to Preview/Advanced mode. (7) Playback Switch to Playback mode. This allows you to view the recorded video file. (8) Status bar Display the recorded date, time and play speed. (9) Camera ID Show the number of cameras that are being viewed. When you are in single screen mode, click the camera ID number to switch and view other camera.

  • Page 58: Appendix A Registering Domain Name

    Appendix A Registering Domain Name DDNS (Dynamic Domain Name Service) is a data query service mainly used on the Internet for translating domain names into Internet addresses. It allows remote clients to intelligently search dynamic servers without any previous enquiring for servers’ Internet addresses. In order to take advantage of this intelligent service, first register your domain name on the following Web site http://ddns.avers.com.tw User Login...

  • Page 59: Appendix B Network Service Port

    Appendix B Network Service Port The following table shows the ports that DVR server uses for certain network service. Port# Variable Remote Console 5550 WebViewer CM3000 Firmware Update 5005 DVR DDNS (Upload / Download) 53/1053...

  • Page 60: Appendix C Using Functional Keys

    Appendix C Using Functional Keys The DVR system provides shortcut keys. The table shows the function keys and descriptions. Function Keys Description Exit System Display system information Start recording Enable network function Access system settings Switch to playback mode Access PTZ camera control panel Snapshot Switch to Full Screen Switch to AutoScan...

  • Page 61: Warranty Notice

    Any other cause which does not relate to a product defect 3. Cartons, cases, batteries, cabinets, tapes, or accessories used with product 4. AVerMedia does not warrant that this product will meet your requirements; it is your responsibility to determine the suitability of this product for your purpose WHAT WE WILL AND WILL NOT PAY FOR We will pay labor and material expenses for covered items.
