Messages regarding printheads

Cannot adjust printhead. ................................................................................................................................ 827

Wrong printhead. ............................................................................................................................................ 827

Printhead error ................................................................................................................................................ 827

No printhead ................................................................................................................................................... 828
Execute printhead cleaning. ........................................................................................................................... 828
Cannot adjust printhead.
Cause
The Printhead noz-
zles are clogged.
The Printhead can-
not be aligned; high-
ly transparent film is
loaded.
The Printhead is in-
stalled crooked.
Wrong printhead.
Cause
An incompatible Printhead has been installed.
Printhead error
Cause
There is a problem with the Printhead.
iPF650
Execute Head Posi. Adj. again, as follows.
1. Press the OK button to clear the error.
2. Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.")
3. Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.")
4. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).")
→P.619
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjust-
ment.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).")
Straighten the Printhead as follows, and then execute Head Posi. Adj. again.
1. Press the OK button to clear the error.
2. Use Head Inc. Adj. to adjust the angle of inclination of the Printhead.
(See "Adjusting Line Misalignment (Head Inc. Adj.).")
3. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).")
→P.619
Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.")
Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.")
Error Message
Corrective Action
→P.740
→P.741
→P.623
Corrective Action
→P.742
Corrective Action
→P.742
> Messages regarding printheads >
→P.619
Cannot adjust printhead.
12
827
