Adjustments for Better Print Quality
Note
• Always check the Adj. Priority values before using Manual adjustment.
(See "Selecting a Feed Amount Adjustment Method (Feed Priority).")
• If additional fine-tuning is necessary after Manual adjustment, use Adj. Fine Feed
(See "Fine-Tuning the Paper Feed Amount (Adj. Fine Feed).")
• Use Adjust Length to ensure that lines in CAD drawings are printed at exactly the right length.
(See "Adjusting Line Length (Adjust Length).")
• Use paper of the same type and size for adjustment as you will use for printing.
Paper to Prepare
Rolls An unused roll at least 10 inches wide
Sheets Two sheets of unused paper of at least A4/Letter size
Perform adjustment as follows.
1.
Load the paper.
• Attaching the Roll Holder to Rolls
• Loading Rolls in the Printer
• Loading Sheets in the Printer
6
2.
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab (
3.
Press the OK button.
The Set./Adj. Menu is displayed.
632
4.
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5.
Press ▲ or ▼ to select Feed Priority, and then press the OK button.
6.
Press ▲ or ▼ to select Adj. Quality, and then press the OK button.
Manual Banding Adjustment (Adj. Quality)
> Adjusting the feed amount
→P.579
→P.602
Note
• Always make sure the loaded paper matches the type of paper specified. Adjustment cannot be com-
pleted correctly unless the loaded paper matches the settings.
Note
• If the Tab Selection screen is not displayed, press the Menu button.
>
→P.634
→P.575
→P.628
→P.633
).
