HP-GL/2 jobs are printed in monochrome (or color)

Cause
The Color Mode setting in
the Control Panel menu is in-
correct.

Printed colors of lines are inaccurate during HP-GL/2 printing

Cause
AdjustFaintLines is On in the
Control Panel menu.

HP-GL/2 jobs are printed 6 mm larger than specified

The page size of the HP-GL/2 print job, as created in the
source application, is incorrect.

HP-GL/2 jobs are printed at maximum size, even if a standard size is specified

Cause
The page size of the HP-GL/2 print job, as
created in the source application, is incor-
rect.

HP-GL/2 printing takes a long time

Large print jobs with a lot of data take longer to print.
A job was printed when Input Resolution in the Con-
trol Panel menu was set to 600dpi.
iPF650
Check the Color Mode setting in the Control Panel menu.
(See "Menu Settings.")
However, for optimal Printhead performance, the printer consumes trace amounts of
color ink even when Monochrome is selected as Color Mode.
Setting AdjustFaintLines to Off in the Control Panel menu may help produce the
expected results. However, lines in some colors may appear broken.
Cause
In the Control Panel menu, set PageSizeProcess2 or Conserve Paper to
On.
The layout will be changed to the optimal layout.
(See "Menu Settings.")
Cause
Troubleshooting
Corrective Action
→P.674
Corrective Action
Corrective Action
In the Control Panel menu, set PageSizeProcess1 to On.
(See "Menu Settings.")
→P.674
Corrective Action
→P.674
Corrective Action
Please wait a while until printing is finished.
In the Control Panel menu, set Input Resolution to 300dpi
and print again.
(See "Menu Settings.")
→P.674
HP-GL/2 jobs are printed in monochrome (or color)
> HP-GL/2 problems >
