Control Panel
8
a. Display Screen
Shows printer menus, as well as the printer status and messages.
b. Data Lamp (green)
• Flashing
During printing, the Data lamp flashes when the printer is receiving or processing print jobs. Otherwise, this lamp
flashes when the print job is paused or the printer is updating the firmware.
• Off
There are no active print jobs when the Data lamp is off.
