Replacing the Printhead
1
If the roll is not ejected because of the cutting method selected, cut it manually and remove it. (See "Cutting
Roll Paper After Printing.")
2
Clean inside the Top Cover. (See "Cleaning Inside the Top Cover.")
3
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
•
Note
4
Press the OK button.
The Set./Adj. Menu is displayed.
5
Press ▲ or ▼ to select Maintenance, and then press the OK button.
6
Press ▲ or ▼ to select Replace P.head, and then press the OK button.
Ink is now drawn into the Maintenance Cartridge.
After about two minutes, a message is shown on the Display Screen instructing you to open the Top Cover.
Replace the Printhead
1
Open the Top Cover.
Instructions are now shown on the Display Screen regarding
Printhead replacement.
Important
630
→P.171
).
If the Tab Selection screen is not displayed, press the Menu button.
•
During Printhead replacement, do not move the Carriage from the position indicated. If you accidentally move the
Carriage, you will hear a warning tone, and Printhead replacement is no longer possible.
If you move the Carriage by mistake, close the Top Cover. The Carriage will be moved to the position as indicated.
→P.642
