With HP-GL/2, printing is misaligned

HP-GL/2 problems

HP-GL/2 problems

With HP-GL/2, printing is misaligned ................................................................................................................. 676

Lines or images are missing in printed HP-GL/2 jobs. ...................................................................................... 676

Lines are printed too thick or thin in HP-GL/2 print jobs .................................................................................... 676

HP-GL/2 jobs are printed in monochrome (or color) .......................................................................................... 676

Printed colors of lines are inaccurate during HP-GL/2 printing ......................................................................... 676

HP-GL/2 jobs are printed 6 mm larger than specified ....................................................................................... 676

HP-GL/2 jobs are printed at maximum size, even if a standard size is specified ............................................. 677
HP-GL/2 printing takes a long time .................................................................................................................... 677
The printer stops when printing a HP-GL/2 job (the carriage stops moving) .................................................... 677
With HP-GL/2, printing is misaligned
With HP-GL/2, printing is misaligned
The plotter origin is incorrect.
The Margin setting in the Control Panel menu is incorrect.
Lines or images are missing in printed HP-GL/2 jobs.
Lines or images are missing in printed HP-GL/2 jobs.
The memory is full.
An HP-GL/2 command not supported by this printer was received.
The printer has received print data that includes HP RTL commands when Auto
Rotate is On in the Control Panel menu.
Lines are printed too thick or thin in HP-GL/2 print jobs
Lines are printed too thick or thin in HP-GL/2 print jobs
Cause
The Width setting in the Con-
trol Panel menu is incorrect.
HP-GL/2 jobs are printed in monochrome (or color) HP-GL/2 jobs are printed in monochrome (or color)
Cause
The Color Mode setting in the
Control Panel menu is incorrect.
Printed colors of lines are inaccurate during HP-GL/2 printing
Printed colors of lines are inaccurate during HP-GL/2 printing
Cause
AdjustFaintLines is On in the Con-
trol Panel menu.
HP-GL/2 jobs are printed 6 mm larger than specified HP-GL/2 jobs are printed 6 mm larger than specified
The page size of the HP-GL/2 print job, as created in the source application, is in-
676
correct.
Cause
Cause
Check the Width setting value specified for Pen no. in Palette A or Palette B in the Control Panel menu. If
fine lines are printed faintly, setting ThickenFineLines to On will print the lines more distinctly.
(See "Menu Settings.")
Check the Color Mode setting in the Control Panel menu.
(See "Menu Settings.")
However, for optimal Printhead performance, the printer consumes trace amounts of color ink even when
Monochrome is selected as Color Mode.
Setting AdjustFaintLines to Off in the Control Panel menu may help produce the expected results.
However, lines in some colors may appear broken.
Cause
Corrective Action
Check the printing commands.
Adjust the Margin setting values in the Control Panel menu.
Check the size of the data in the print job.
Check the print job and settings.
In the Control Panel, set Auto Rotate to Off and print again.
(See "Menu Settings.")
Corrective Action
→P.500
Corrective Action
→P.500
Corrective Action
In the Control Panel menu, set PageSizeProcess1 to On.
(See "Menu Settings.")
iPF765
Corrective Action
→P.500
Corrective Action
→P.500
User's Guide
