Menu Settings
GL2 Set- Line &
tings Pen
Manager
Proces-
singOp-
tion
GL2 Set Print
Interface EOP Timer
Setup
TCP/IP
506
Setting Item
Smoothing
ThickenFineLines
AdjustFaintLines
Warning
On-the-Fly
PageSizeProcess1
PageSizeProcess2
IPv4 IPv4 Mode
Protocol DHCP
BOOTP
RARP
IPv4 Set- IP Address
tings
Subnet Mask
Description, Instructions
•
If you choose Software
Operation is determined by the application. If nothing is
specified by the application, the result is as shown in the
figure.
Note: By default, this is a 72-sided figure
•
If you choose Smooth
Select On to print fine lines more distinctly.
If fine lines are printed in colors that do not match the colors of
other shapes, selecting Off may help produce the expected re-
sults. However, lines in some colors may appear broken.
Select On to have any GL2-related warnings displayed.
Selecting On will start printing jobs sooner if you are printing
only HP RTL print jobs and printing would not start until later.
However, images may be incomplete in some cases, so be
sure to check the printing results.
Normally, the area available for printing excludes a margin re-
quired by the printer, and images are positioned accordingly.
Selecting On in this setting eliminates any misalignment of the
printing position if the image itself includes a border.
Selecting On will determine the paper size based on the image
rendering area.
Print GL2 settings information.
Specify the timeout period before cancellation of print jobs that
cannot be received by the printer.
Choose whether the printer IP address is configured automati-
cally or a static IP address is entered manually.
Specify the protocol used to configure the IP address automati-
cally.
Specify the printer network information when using a static IP
address.
