Removing and Replacing System Batteries

Servers with an iLO MP card have two batteries. Servers that do not have an iLO MP card only
have one battery.
WARNING: There is a danger of explosion if the battery is incorrectly installed. For your safety, never
attempt to recharge, disassemble, or burn an old battery. Replace the battery with the same or equivalent
type, as recommended by the manufacturer.
The battery in this server is a lithium battery that does not contain any heavy metals. However, to protect
the environment, do not dispose of batteries in household waste. Return used batteries either to the shop
from where you bought them, to the dealer from whom you purchased the server, or to HP so that they
can be recycled or disposed of in the correct way. Returned batteries are accepted free of charge.
Removing the System Battery
To remove the system battery, follow these steps:
1. Power off the server, disconnect all power and external cables and remove the server covers.
2. Remove the processor airflow guide.
3. Lift up on the battery and push on the back of it with a flat-head screwdriver to remove the
battery from its holder.
CAUTION: Lift the battery just high enough to clear its holder. Too much stress on the battery holder
retaining clip may break it.

Remove the System Board Battery

Replacing the System Battery
To replace the system battery, follow these steps:
1. Lift up on the battery holder retaining clip with a flat-head screwdriver and slide the battery
into its holder. The positive
CAUTION: Lift the battery just high enough to clear its holder. Too much stress on the battery holder
retaining clip may break it.
2. Replace the processor airflow guide.
HP Integrity rx2600 server and HP workstation zx6000 Operation and Maintenance Guide
(+)
side of the battery should face up.
Removing and Replacing Components
103
