Upgrade Guide
HP Integrity rx2600 / HP 9000 rp34x0 to
HP Integrity rx2620
Manufacturing Part Number: AB359-90002
Second Edition
June 2005
© Copyright 2005 Hewlett-Packard Development Company, L.P.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Integrity rx2600 and is the answer not in the manual?

Questions and answers

Related Manuals for HP Integrity rx2600

Summary of Contents for HP Integrity rx2600

  • Page 1 Upgrade Guide HP Integrity rx2600 / HP 9000 rp34x0 to HP Integrity rx2620 Manufacturing Part Number: AB359-90002 Second Edition June 2005 © Copyright 2005 Hewlett-Packard Development Company, L.P.
  • Page 2 The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional...

  • Page 3: Table Of Contents

    Upgrade CPU Fans (1A and 1B) ............55 Installing HP Integrity rx2620 Name Plate and Intel Itanium 2 Rack Label ....55 Apply UUID Label (rp34x0) .
  • Page 4 Contents...
  • Page 5 Tables Table 1-1. Upgrade Checklist ............14 Table 1-2.
  • Page 6 Tables...
  • Page 7 Figure 1-1. Release the Rack Latches ..........21 Figure 1-2. Pedestal Mounted HP Integrity rx2600 or HP9000 rp34x0 Server ....22 Figure 1-3.
  • Page 8 Figures Figure 1-44. Connecting the Power Pod Cable ......... 50 Figure 1-45.
  • Page 9 • Printing History Intended Audience This document is intended to provide technical product and support information for authorized service providers, customer system administrators, and HP support personnel. What’s New? • The layout of this document was changed to improve usability •...
  • Page 10 Example screen output is represented using this font. Reader Comments and Feedback HP welcomes your feedback on this publication. Please address your comments to edit@presskit.rsn.hp.com and note that you will not receive an immediate reply. All comments are appreciated. Related Information You can find other information on HP server hardware management, Microsoft®...
  • Page 11 • HP-UX Virtual Partitions http://www.hp.com/hpbooks/prentice/ptr_0130352128.html HP Books are available worldwide through bookstores, online booksellers, and office and computer stores. Printing History The Printing History below identifies the edition dates of this manual. Updates are made to this publication on an unscheduled, as needed, basis. The updates will consist of a complete replacement manual and pertinent on-line or CD-ROM documentation.

  • Page 13: Introduction

    “System Validation and Reconfiguration Procedures After Hardware Upgrade from rp34x0” Time Required Upgrading your HP Integrity rx2600 server or HP 9000 rp34x0 server to an HP Integrity rx2620 server may require several hours, depending on preparatory time, but you should plan for one hour of system downtime.

  • Page 14: Upgrade Checklist

    HP Integrity rx2620 Upgrade Upgrade Checklist Upgrade Checklist Use the following checklist to assist in completing your upgrade from an HP Integrity rx2600 server or HP 9000 rp34x0 server to an HP Integrity rx2620 server. Table 1-1 Upgrade Checklist Step...

  • Page 15: Upgrade Kit Contents

    HP Integrity rx2620 Upgrade Upgrade Kit Contents Upgrade Kit Contents The following items comprise the contents of the upgrade kit. The hardware components listed under the “Additional Upgrade Components Required” list are also required for the upgrade, but must be ordered separately.

  • Page 16: Service Tools Required

    HP Integrity rx2620 Upgrade Service Tools Required Service Tools Required Service of this product may require one or more of the following tools: • IPF CPU Install Tool Kit (P/N 5069-5441), consisting of: • Disposable ESD Kit • Label-less CPU install tool (2.5mm hex and Torx 15) •...

  • Page 17: Safety And Environmental Considerations

    Installing and using the system in strict accordance with HP's instructions minimizes the chances that the system will cause radio or television interference. However, HP does not guarantee that the system will not interfere with radio and television reception.

  • Page 18: Upgrade Preparation And System Shutdown

    HP Integrity rx2620 Upgrade Upgrade Preparation and System Shutdown • Treat all assemblies, components, and interface connections as static-sensitive. • When unpacking cards, interfaces, and other accessories that are packaged separately from the system, keep the accessories in their conductive plastic bags, until they are ready to be installed.

  • Page 19: Lan Requirements

    0/1/2/1 0x000E7F7E101D lan2 snap2 ETHER Yes Use the appropriate operating system tool (for example, ifconfig for HP-UX) to validate your NOTE LAN configuration. Back Up Your System Before performing the server upgrade, protect yourself by backing up all data and your server OS. In the event of interruptions (for example power failure or interference), it may be necessary to resume operation in the old configuration before upgrading the server.

  • Page 20: Removing System Top Metal Cover And Bezel

    Accessing a Rack Mounted Server The HP Integrity rx2620 server is designed to be rack mounted. The following procedure explains how to gain access to an HP Integrity rx26xx or rp34xx server that is mounted in an approved rack.

  • Page 21: Figure 1-1 Release The Rack Latches

    Accessing an rx2600 or rp34x0 Pedestal Mounted Server The HP Integrity rx2600 and HP 9000 rp34x0 servers are also designed to be pedestal mounted. You do not need to remove the pedestal from the HP server to gain access to internal components. The front bezel, front cover, and top cover may be removed with the pedestal attached to the HP server.

  • Page 22: Figure 1-2 Pedestal Mounted Hp Integrity Rx2600 Or Hp9000 Rp34X0 Server

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-2 Pedestal Mounted HP Integrity rx2600 or HP9000 rp34x0 Server Chapter 1...

  • Page 23: Figure 1-3 Removing The Top Metal Cover

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Removing the Top Metal Cover Step 1. Ensure the top metal cover lock keyswitch is in the unlocked position. Rotate the blue release lever toward the back of the system and slide the cover toward the back of the system.

  • Page 24: Processor

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Removing System Fans, PCI Card Cage, Airflow Guides, Memory, Processors, and the Management Processor Location of Internal Components and Connectors Figure 1-5 Internal Physical Layout Pwr 2 Pwr 2 Pwr 1...

  • Page 25: Table 1-4. Connector Locations

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-6 System Board Connectors and Slots SCSI CH A SCSI CH B 12 11 Front of Chassis Table 1-4 Connector Locations 1 External SCSI Connector 9 Power Module Power Connector...

  • Page 26: Figure 1-7 Fan 1A Or Fan 1B Removal

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Removing System Fans Step 1. To remove fans 1A, 1B, 2 and 3 from the system, grasp the appropriate fan and lift it out of the fan socket. Figure 1-7 Fan 1A or Fan 1B Removal...

  • Page 27: Figure 1-9 Fan 3 Removal

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-9 Fan 3 Removal Fan 3 Front of Chassis Removing Airflow Guides The system has the following airflow guides: Figure 1-10 Airflow Guides Locations Processor Airflow Guide Memory Airflow Guide...

  • Page 28: Figure 1-11 Removing The Memory Airflow Guide

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-11 Removing the Memory Airflow Guide Front of Chassis Removing the Processor Airflow Guide Step 1. Remove the IDE cable and power module cables from the processor airflow guide cable clips.

  • Page 29: Figure 1-13 Open The Release Clip

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 3. Remove the front portion of the airflow guide: a. Rotate the clip clockwise to release the latch. Figure 1-13 Open the Release Clip Front of Chassis Step 4. Disconnect the power cable connected to the guide from the system board.

  • Page 30: Figure 1-14 Remove The Front Airflow Guide

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-14 Remove the Front Airflow Guide Front of Chassis Removing System Memory Next, remove all system memory by performing the following steps: Step 1. Push the appropriate extraction levers found on either side of the DIMM slot outward to the open position.

  • Page 31: Figure 1-15. Processor Location

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Removing Processor Modules Figure 1-15 Processor Location Power Pod CPU 0 CPU 1 Power Pod CPU 1 CPU 0 Front of Chassis Chapter 1...

  • Page 32: Figure 1-16 Disconnect Power Pod Cable

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 1. Disconnect the power pod cable from the power connector on the system board. Figure 1-16 Disconnect Power Pod Cable Front of Chassis Step 2. Remove the two power pod mounting screws.

  • Page 33: Figure 1-18 Disconnect Power Pod From Processor Module

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 3. Slide the power pod toward the rear of the system board disconnecting the power pod from the processor module. Figure 1-18 Disconnect Power Pod from Processor Module Front of Chassis Step 4.

  • Page 34: Figure 1-19 Remove Power Pod

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-19 Remove Power Pod Front of Chassis Step 5. Disconnect the processor module turbo fan power cable. Figure 1-20 Disconnect the Turbo Fan Cable Front of Chassis Chapter 1...

  • Page 35: Figure 1-21 Release Heatsink Captive Screws

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 6. Release the four heatsink captive screws on the processor module heat sink. Figure 1-21 Release Heatsink Captive Screws Front of Chassis Step 7. Slide the sequencing retainer plate toward the back of the system to open the hole in the edge of the heatsink for insertion of the special processor tool into the processor module locking mechanism.

  • Page 36: Figure 1-23 Unlock Processor Module Locking Mechanism

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 8. Unlock the processor-locking mechanism using the special processor tool (P/N 5069-5441), or equivalent 2.5 mm hex tool, shipped with your replacement processor assembly. Insert the tool into the lock and rotate the special processor tool 180 degrees counterclockwise. Verify that the processor-locking mechanism is rotated into the unlocked position.

  • Page 37: Figure 1-24 Remove Processor Module

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 9. Lift the processor module and the turbo fan assembly up and out of the chassis. Place the processor module into an anti-static container. Carefully handle the CPU to avoid damaging the pins. If possible, cover the WARNING exposed CPU pins with a pin cover.

  • Page 38: Figure 1-25 Removing The Ilo Manageability Card

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Removing the iLO Manageability Card Step 1. Unscrew the two mounting screws that connect the iLO Manageability card to the internal chassis post and the two external mounting screws that are located on both sides of the 25-pin serial connector.

  • Page 39: Figure 1-26 Removing The Pci Card Cage

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Removing the PCI Card Cage To remove the PCI cage from the server, perform the following steps: Step 1. Lift up on the PCI card cage release lever and the back edge of the PCI card cage and lift the PCI card cage out of the system.

  • Page 40: Figure 1-27 Vga And Db9 Mechanical Cover Locations

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-27 VGA and DB9 Mechanical Cover Locations VGA cover DB9 cover Rear of chassis Step 4. Unscrew the six backplane system board mounting screws that connect the system board to the rear of the system chassis.

  • Page 41: Figure 1-29 Remove The System Board Mounting Screw

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-29 Remove the System Board Mounting Screw Front of Chassis Step 7. Remove the system board: a. Grasp the memory controller chip heatsink and slide the system board toward the front of the system.

  • Page 42: Upgrading The System Board

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions In rp34x0 machines, the VGA and secondary LAN ports are not functional. A label on the rear of the rp34x0 chassis designates the VGA port as Not Available and covers the secondary LAN port. Before the system board is upgraded, the label must be removed.

  • Page 43: Figure 1-33 Slide System Board Into Chassis

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions a. Angle the board to allow the PCI connector to slide into the PCI cage bay area. Figure 1-33 Slide System Board into Chassis Front of Chassis b. Align the system board keyholes with their standoffs on the chassis.

  • Page 44: Figure 1-34 Align The System Board Pci Connector

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-34 Align the System Board PCI Connector Front of Chassis Step 3. Slide the system board back toward the rear of the system to secure the system board on its standoffs.

  • Page 45: Figure 1-36 Install The Rear Panel Mounting Screws

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Step 4. Screw in the system board mounting screw. Step 5. Connect all cables to their appropriate connectors on the system board. Step 6. Screw in the six rear backplane system board mounting screws.

  • Page 46: Upgrading The Cpus

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Upgrading the CPUs Installing the New Processor Module Step 1. Verify part number of the CPU (AB334A, AB335A or AB336A). Ensure that each processor has an identical part number when installing more than NOTE one processor.

  • Page 47: Figure 1-38 Locking The Processor Module In Place

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-38 Locking the Processor Module in Place Unlocked Locked Front of Chassis Step 5. Slide the sequencing retainer plate toward the rear of the system. Figure 1-39 Slide the Sequencing Retainer Plate Front of Chassis Step 6.

  • Page 48: Figure 1-40 Secure The Captive Screws

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-40 Secure the Captive Screws Torquing pattern Front of Chassis Step 7. Slide the power module on the system board metal mounting bracket so that the power module connector connects with its connector on the processor module.

  • Page 49: Figure 1-42 Install The Processor Module Power Pod Mounting Screws

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-42 Install the Processor Module Power Pod Mounting Screws Front of Chassis Step 9. Connect the processor module turbo fan power cable to the connector on the system board. Figure 1-43 Connect the Turbo Fan Cable Front of Chassis Step 10.

  • Page 50: Reinstalling System Fans, Pci Card Cage, Airflow Guides, Memory, And The Management Processor

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-44 Connecting the Power Pod Cable Front of Chassis Reinstalling System Fans, PCI Card Cage, Airflow Guides, Memory, and the Management Processor Reinstall the Management Processor NOTE Connect SCSI cables before replacing the Management Processor.

  • Page 51: Figure 1-45 Reinstall The Power Connectors

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-45 Reinstall the Power Connectors Front of Chassis Chapter 1...
  • Page 52 Memory modules must be loaded in the correct order: • In the HP Integrity rx2620 server, DIMMs must be installed in matched quads. Two matched memory card pairs of equal size (that is, four identical DIMMs) must be installed, one pair per memory cell, as listed below: —...

  • Page 53: Figure 1-46 Inserting Dimm Into Slot

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-46 Inserting DIMM into Slot Reinstalling Air Flow Guides Figure 1-47 Airflow Guides Locations Processor Airflow Guide Memory Airflow Guide Front of Chassis Reinstalling the Memory Airflow Guide Step 1. Align the guides on both sides of the original airflow guide with the slots on the chassis.
  • Page 54 HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions b. Connect power connector on the front portion of the guide to the connector on the system board. Step 2. Reinstall the main portion of the original airflow guide: a. Hold the opening on top of the processor airflow guide.

  • Page 55: Upgrade Cpu Fans (1A And 1B)

    Installing HP Integrity rx2620 Name Plate and Intel Itanium 2 Rack Label To install the HP Integrity rx2620 server name plate and Intel Itanium 2 rack label, follow these steps: Step 1. Locate the name plate release prongs on the back side of the system bezel.

  • Page 56: Replacing The Front Bezel And Top Metal Cover

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Replacing the Front Bezel and Top Metal Cover Replacing the Front Bezel To install the front bezel, perform the following step: Step 1. Push the front bezel straight into the chassis until it snaps into place.

  • Page 57: Figure 1-49 Aligning The Top Metal Cover

    HP Integrity rx2620 Upgrade System Hardware Component Upgrade Instructions Figure 1-49 Aligning the Top Metal Cover To replace cover, align front edge here then slide forward Front of Chassis Step 2. Grasp the blue release lever and slide the top metal cover toward the front of the system until the lever snaps into place.

  • Page 58: System Validation And Reconfiguration Procedures After Hardware Upgrade From Rx2600

    HP Integrity rx2620 Upgrade System Validation and Reconfiguration Procedures After Hardware Upgrade from rx2600 System Validation and Reconfiguration Procedures After Hardware Upgrade from rx2600 The system board upgrade part is configured at the factory with default product, serial and UUID IDs. After replacing the system board, factory default ID values must be overwritten with actual system values.

  • Page 59: System Validation And Reconfiguration Procedures After Hardware Upgrade From Rp34X0

    HP Integrity rx2620 Upgrade System Validation and Reconfiguration Procedures After Hardware Upgrade from rp34x0 System Validation and Reconfiguration Procedures After Hardware Upgrade from rp34x0 The system board upgrade part is configured at the factory with default product, serial and UUID IDs. After replacing the system board, factory default ID values must be overwritten with actual system values.
  • Page 60 HP Integrity rx2620 Upgrade System Validation and Reconfiguration Procedures After Hardware Upgrade from rp34x0 NOTE The product number is now rx2620 and the product, serial and UUID number values are populated. SYSTEM INFORMATION Date/Time: 3, 2004 15:34:26 (20:04:08:03:15:34:26) Manufacturer: Product Name:...

  • Page 61: Raid - Smart Array 6402 Or 6404 Controller For Internal Raid Installation

    • Confirm that the Smart Array 6402 or 6404 controller and software are supported on the HP Integrity server and I/O slot chosen. Refer to the Smart Array Controller Support Matrix located at http://www.docs.hp.com in the Networking & Communications section for more information.

  • Page 62: Pci Slots

    Cable A7231-63024 is used for the single channel or simplex RAID card • Cable A7231-63025 is used for the dual channel or duplex RAID card Before installing the RAID card, refer to the Internal Cabling Guide for HP Smart Array Controllers HP P/N 5971-4280 available at http://www.docs.hp.com. PCI Slots Before inserting a RAID card, be certain of which PCI slots are available for RAID, and if the slot can be used for internal or external RAID.

  • Page 63: Table 2-2 Raid Card Components

    RAID - Smart Array 6402 or 6404 Controller for Internal RAID Installation Smart Array 6402 RAID or 6404 RAID Cards Step 6. Install the Install the Smart Array 6402 or 6404 card. Figure 2-1 Smart Array 6402 RAID Card (SA 6404 RAID Card not shown) The following table lists the RAID card components.

  • Page 64: Installing Smart Array Raid For Duplex Configuration

    Step 2. Shut down the system. Step 3. Power off the system, and unplug the power cord. Step 4. Remove the PCI card cage (refer to “Removing and Replacing PCI Cards” in the HP rx2620 Maintenance Guide. Step 5. Disconnect the SCSI cable(s) from the internal SCSI backplane.

  • Page 65: Setting Up A Smart Array Raid Card As A Boot Device

    Offline Configuration of HP-UX 11i v1 or HP-UX 11i v2 Using Ignite-UX To set up a Smart Array 6402 Controller as a boot device, you must install HP-UX 11i v1 or HP-UX 11i v2 on one of the controller’s logical drives. Follow this procedure: Step 1.
  • Page 66 The system reboots and you are returned to the Boot Console Handler (BCH) prompt. Step 9. At the BCH prompt, start Ignite-UX from the HP-UX 11i v1 or HP-UX 11i v2 Core OS Install and Recovery Media. The Ignite-UX Welcome screen displays (see Step 1).

  • Page 67: Configuring The Server For Raid

    Install and use operating system-specific HP Smart Array 6402 and HP Smart Array 6404 utilities and software that help you manage your RAID. • Configure the HP Smart Array 6402 and the HP Smart Array 6404 for an external RAID storage system. Chapter 2...
  • Page 68 RAID - Smart Array 6402 or 6404 Controller for Internal RAID Installation Smart Array 6402 RAID or 6404 RAID Cards Chapter 2...

  • Page 69: Index

    Index communications interference component locations connector locations electrostatic discharge environmental considerations ESD precautions ESD kit, part number interference location pull tab management processor card removing and replacing processor location processor airflow guide removing and replacing removing and replacing management processor card processor airflow guide system board system covers and bezels...
