Appendix B - Cabling Diagrams
Command Port Cable
LAN Cable
Pin
1
2
3
6
Voice/Fax Channel Connectors
Pin Connections
E&M
1
2
3
4
5
6
7
8
Circuit Signal Name
TD+ Data Transmit Positive
TD- Data Transmit Negative
RD+ Data Receive Positive
RD- Data Receive Negative
Description
M
E
T1
R
T
R1
SG
SB
FXO
Description
1
N/C
2
Ring
3
Tip
4
N/C
Appendix B - Cabling Diagrams
FXS
Description
1
N/C
2
Tip
3
Ring
4
N/C
73
