  • Page 1 ® SocketModem Cell LTE MTSMC-Lxx Device Guide...
  • Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
  • Page 3 CONTENTS Contents Chapter 1 – Product Overview ..........................6 Product Overview................................6 Documentation ................................6 Product Build Options ..............................7 Chapter 2 – Mechanical Drawings..........................8 MTSMC-Lxxx.................................. 8 MTSMC-Lxxx-U ................................9 Chapter 3 – Specifications ............................10 MTSMC-LAT1 and MTSMC-LAT1-U Specifications ...................... 10 MTSMC-LVW2 and MTSMC-LVW2-U Specifications ....................
  • Page 4 Placing GPS Antennas .............................. 24 Antenna Approvals and Safety Considerations ......................24 Diversity and Power Draw ............................25 GPS Antenna Specifications ............................25 MultiTech Ordering Information..........................25 Antenna Specifications.............................. 25 OEM Integration ................................. 25 FCC & IC Information to Consumers ......................... 25 FCC Grant Notes................................
  • Page 5 CONTENTS Information on HS/TS Substances According to Chinese Standards ................. 40 Information on HS/TS Substances According to Chinese Standards (in Chinese) ............41 Chapter 8 – Labels..............................42 Approvals and Certifications ............................42 Example Labels................................42 Chapter 9 – Using Connection Manager ......................... 44 Installing Connection Manager ...........................
  • Page 6 LTE Cat 1 Cat 4 performance. These quick-to-market communications devices allow developers to add wireless communication to products with a minimum of development time and expense. SocketModem Cell models are based on industry-standard open interfaces and use MultiTech’s Universal Socket design. Documentation The following documentation is available at multitech.com/support.
  • Page 7 PRODUCT OVERVIEW Product Build Options Product Description Carrier/Region MTSMC-LVW2 4G LTE embedded cellular modem with GPS/GLONASS Verizon (Serial Interface) MTSMC-LVW2-U 4G LTE embedded cellular modem with GPS/GLONASS Verizon (USB Interface) MTSMC-LEU1 (RED 4G LTE with HSPA+ fallback embedded cellular modem Europe/Australia Compliant) with GPS/GLONASS (Serial Interface)
  • Page 8 MECHANICAL DRAWINGS Chapter 2 – Mechanical Drawings MTSMC-Lxxx ® SocketModem Cell LTE MTSMC-Lxx Device Guide...
  • Page 9 MECHANICAL DRAWINGS MTSMC-Lxxx-U ® SocketModem Cell LTE MTSMC-Lxx Device Guide...
  • Page 10 SPECIFICATIONS Chapter 3 – Specifications MTSMC-LAT1 and MTSMC-LAT1-U Specifications Category Description General Standards LTE 3GPP Release 9 HSPA+ 21/GPRS fallback USB Interface is CDC-ACM compliant TCP/IP Functions FTP, SMTP, SSL, TCP, UDP Frequency Bands 4G: 700 (B17)/850 (B5)/AWS 1700 (B4)/1900 (B2) 3G: 850 (B5)/1900 (B2) 2G: 850/1900 Speed...
  • Page 11 SPECIFICATIONS Category Description Point-to-Point messaging Mobile-Terminated SMS Mobile-Originated SMS Certifications and Compliance EMC Compliance FCC Part 15 Class B Radio Compliance FCC Part 22, 24, 27 Safety Compliance UL 60950-1 2nd ED cUL 60950-1 2nd ED IEC 60950-1 2nd ED Network Compliance PTCRB Carrier...
  • Page 12 SPECIFICATIONS Category Description Storage Temperature -40° C to +85° C Humidity 20%-90% RH, non-condensing Power Requirements Input Voltage 3.3-5 VDC Point-to-Point messaging Mobile-Terminated SMS Mobile-Originated SMS Certifications and Compliance EMC Compliance FCC Part 15 Class B Radio Compliance FCC Part 27 Safety Compliance UL 60950-1 2nd ED cUL 60950-1 2nd ED...
  • Page 13 SPECIFICATIONS Category Description Connectors Antenna Connector 3 surface mount UFL connectors for cellular, Rx diversity/MIMO, and GPS 1.8V and 3V SIM holder for mini-SIM card Environment Operating Temperature -40° C to +85° C Storage Temperature -40° C to +85° C Humidity 20%-90% RH, non-condensing Power Requirements...
  • Page 14 SPECIFICATIONS Mode Freq. TX (MHz) Freq. RX (MHz) Channels TX - RX offset LTE800 (band XX) 832 - 862 791 - 821 -41MHz Tx: 24150 - 24449 Rx: 6150 - 6449 LTE1800 (band III) 1710 - 1785 1805 - 1880 95MHz Tx: 19200 - 19949...
  • Page 15 SPECIFICATIONS LE910 Telit Transmission Output Power Band Power Class GSM 850/900 MHz 4 (2W) DCS 1800, PCS 1900 MHz 1 (1W) EDGE, 850/900 MHz E2 (0.5W) EDGE, 1800/1900 MHz Class E2 (0.4W) WCDMA/FDD 800/850/900, 1900/2100 MHz Class 3 (0.25W) LTE FDD 700/800/850/900, 1800/1900/2100/2600 Class 3 (0.2W) Underwriters Laboratories, Inc.
  • Page 16 SPECIFICATIONS Signal Name Signal Name -DTR Parameter Minimum Maximum 3.3 Volt Powered Input Low Level 0.55 Input High Level Output Low Level 0.55 Output High Level 2.35 5 Volt Powered Input Low Level Input High Level Output Low Level 0.55 Output High Level Absolute Maximum Rating All models can run with an input voltage of either 3.3V or 5V.
  • Page 17 SPECIFICATIONS Signal Name Logic Level Voltage In/Out Description Ground USB DP USB data USB DN USB data –RTS Request to send (active low) –RXD Received data (active low) –TXD Transmitted data (active low) –RI Ring indicator (active low) –DSR Data set ready (active low) –CTS Clear to send (active low) –DCD...
  • Page 18 SPECIFICATIONS Signal Name Serial Only USB Only –LED LINK ® SocketModem Cell LTE MTSMC-Lxx Device Guide...
  • Page 19 SPECIFICATIONS Power Measurements Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when determining product load. Note: The following notes apply to the following tables. Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE connection.
  • Page 20 SPECIFICATIONS MTSMC-LVW2 Power Draw Radio Protocol Sleep Mode Cellular Call Box Average Measured TX Pulse (Avg) Total Inrush Current (If Connection No Current (Amps) at Amplitude Charge Applicable) Data (Amps) Maximum Power Current (Amps) ) Measured in (Amps) for GSM850 or Millicoulombs Peak Current for (mC)
  • Page 21 SPECIFICATIONS MTSMC-LEU1-U Power Draw Radio Protocol Sleep Mode Cellular Call Box Average Measured TX Pulse (Avg) Total Inrush Current (If Connection No Current (Amps) at Amplitude Charge Applicable) Data (Amps) Maximum Power Current (Amps) ) Measured in (Amps) for GSM850 or Millicoulombs Peak Current for (mC)
  • Page 22 The antenna must be the same type, with similar performance and in- and out-of-band radiation patterns as the listed antenna. The antenna used must stay below the FCC/IC maximum gain. For our bundles, MultiTech may change antennas over time. The listed antenna(s) is used as a reference or was shipping when this document was last updated.
  • Page 23 Radiation Omni-directional Polarization Linear Wieson Antenna Devices were approved with the following antenna: Manufacturer: Wieson Description: LTE GY115HT467-017 Model Number: 11320Y11194A1 MultiTech ordering information: Model Quantity ANLTE2-1HRA ANLTE2-10HRA ANLTE2-50HRA Antenna Specifications Category Description Frequency Range .069~0.96GHz, 1.71~2.17GHz, 2.3GHz~2.69GHz Impedance 50 Ohms...
  • Page 24 Some environments are harsher on particular bands. MultiTech products have antenna connectors at the best spacing for the product size. Placing antennas in close proximity to each other is not optimal, but you can do it if necessary. It depends on the signal strength to and from each antenna.
  • Page 25 ANTENNAS Safety requirements depend on your final product. Unless otherwise noted, antennas certified by MultiTech are not approved for outdoor use. Do not extend these antennas outside of any building. Diversity and Power Draw There are no significant power draw differences.
  • Page 26 ANTENNAS FCC Grant Notes The OEM should follow all the grant notes listed below. Otherwise, further testing and device approvals may be necessary. FCC Definitions Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user.
  • Page 27 SAFETY INFORMATION Chapter 5 – Safety Information Handling Precautions To avoid damage due to the accumulation of static charge, use proper precautions when handling any cellular device. Although input protection circuitry has been incorporated into the devices to minimize the effect of static build-up, use proper precautions to avoid exposure to electronic discharge during handling and mounting the device.
  • Page 28 SAFETY INFORMATION Éteignez votre appareil sans fil dans les avions. L'utilisation d'appareils électroniques portables en avion est illégale: elle peut fortement perturber le fonctionnement de l'appareil et désactiver le réseau cellulaire. S'il ne respecte pas cette consigne, le responsable peut voir son accès aux services cellulaires suspendu ou interdit, peut être poursuivi en justice, ou les deux.
  • Page 29 Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty.
  • Page 30 Council Directive 2014/53/EU on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity. MultiTech declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The declaration of conformity may be requested at https://support.multitech.com.
  • Page 31 REGULATORY INFORMATION l'appareil ne doit pas produire de brouillage, et l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. FCC Grant Information MTSMC-LAT1 and MTSMC-LAT1-UMTCDT-LAT1 FCC Part 15 FCC Identifier: RI7LE910NA Equipment Class: Part 15 Class Computing Device Peripheral Notes: LTE/3G/2G Module...
  • Page 32 REGULATORY INFORMATION FCC Rule Parts Frequency Range Output Watts Frequency Emission Designators (MHz) Tolerance 826.5-846.5 0.16904 1.0 PM 4M50D7W 829.0-844.0 0.19409 1.0 PM 9M00G7W 829.0-844.0 0.16331 1.0 PM 9M00D7W 1712.5-1752.5 0.17378 1.0 PM 4M51G7W 1712.5-1752.5 0.17906 1.0 PM 4M51D7W 1715.0-1750.0 0.1803 1.0 PM 9M01G7W...
  • Page 33 REGULATORY INFORMATION MTSMC-LVW2 and MTSMC-LVW2-U FCC Part 15 FCC Identifier: RI7LE910SV Equipment Class: Part 15 Class Computing Device Peripheral Notes: LTE Module FCC Rule Parts: Approval: Single Modular FCC Parts 27 FCC Identifier: RI7LE910SV Equipment Class: Licensed Non-Broadcast Station Transmitter Notes: LTE Module Approval:...
  • Page 34 REGULATORY INFORMATION MTSMC-LAT1 and MTSMC-LAT1-UMTCDT-LAT1 5131A-LE910NA Certification Number/No. de Certification Type of Radio Equipment/Genre de Matériel Advanced Wireless Services Equipment/Matériel des services sans fil évolués (1710-1755 MHz and 2110-2155 MHz) Cellular Mobile GSM/ Téléphone cellulaire mobile GSM (824-849 MHZ) Cellular Mobile New Technologies/Téléphone cellulaire mobile - Nouvelles technologies (824-849 MHz) PCS Mobile/Téléphone mobile SCP (1850-1910 MHz) Mobile Broadband Service (MBS)/Matériel du service...
  • Page 35 REGULATORY INFORMATION Specification/Ca Issue/Édit From Emmission Minimu Maximum Power hier des Charges Frequency/D Frequency Designation/Desig e Fréquences /Á nation D’émission Power Fréquence RSS132 829 M 844 M 9M00D7W 163.31 163.31 mW RSS139 1.713 G 1.752 G 4M51G7W 173.78 173.78 mW RSS133 1.852 G 1.908 G...
  • Page 36 REGULATORY INFORMATION Specification/Ca Issue/Édit From Emmission Minimu Maximum Power hier des Charges Frequency/D Frequency Designation/Desig e Fréquences /Á nation D’émission Power Fréquence RSS133 1.86 G 1.9 G 17M9D7W 175.79 175.79 mW RSS133 1.855 G 1.905 G 8M97D7W 183.23 183.23 mW Certification of equipment means only that the equipment has met the requirements of the above noted specification.
  • Page 37 REGULATORY INFORMATION Specification/Ca Issue/Édit From Emmission Minimu Maximum Power hier des Charges Frequency/D Frequency Designation/Desig e Fréquences /Á nation D’émission Power Fréquence RSS130 779.5 M 784.5 M 5M52G7W 195.43 195.43 mW RSS130 779.5 M 784.5 M 4M53D7W 207.49 207.49 mW RSS139 1.72 G 1.745 G...
  • Page 38 Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.
  • Page 39 2015/863 of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <...
  • Page 40 ENVIRONMENTAL NOTICES Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc.
  • Page 41 ENVIRONMENTAL NOTICES Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部...
  • Page 42 This device is an industry and/or carrier approved modem. In most cases, when integrated and used with an antenna system that was part of the MultiTech modem certification, additional approvals or certifications are not required for the device that you develop as long as the following requirements are met: PTCRB Requirements: The antenna system cannot be altered.
  • Page 43 LABELS MTSMC-LEU1 Package Label MTSMC-LEU1-U Package Label MTSMC-LEU1 Device Label MTSMC-LEU1-U Device Label MTSMC-LVW2 Package Label MTSMC-LVW2-U Package Label MTSMC-LVW2 Device Label MTSMC-LVW2-U Device Label ® SocketModem Cell LTE MTSMC-Lxx Device Guide...
  • Page 44 Click Connection Manager. Open or unzip the Connection Manager file and run the installer (.msi file). In the MultiTech Connection Manager Setup Wizard, read the end-user license agreement and check I accept the terms in the License Agreement. Click Next to have the installer automatically disable the native WWAN AutoConfig service in Windows.
  • Page 45 To specify a folder for Connection Manager, use the default folder or click Change to browse to the folder you want to use. Click Install. A separate wizard opens for installing Telit drivers. Some MultiTech devices use embedded modules from Telit Wireless Solutions to provide cellular connectivity; these devices require Telit drivers. Select Complete setup type.
  • Page 46 USING CONNECTION MANAGER In the Add Hardware Wizard: Click Next. Select Install the hardware that I manually select from a list, then click Next. Select Modems, then click Next. Check Don't detect my modem; I will select it from a list, then click Next. Select Standard Modem Types, then select Standard 33600 bps Modem on the right.
  • Page 47 USING CONNECTION MANAGER Connecting a Device Before You Begin Make sure that your device is connected to the computer where Connection Manager is installed. Set up the device in Device Manager. Refer to Setting Up a Serial Device in Windows Device Manager.
  • Page 48 The steps above describe how to uninstall Connection Manager using Control Panel. You can also uninstall the application by using the installer file (.msi). Double-click the file, in the MultiTech Connection Manager Setup Wizard, click Next, and then select Remove on the next two pages.
  • Page 49 USING CONNECTION MANAGER Connection Details Terminal Charts Main tab The Main tab displays the following: Status of device connection: Searching, Connecting, Connected, Disconnecting, or Disconnected The action button, which changes according to the current device connection status: Detect, Connect, or Disconnect Signal strength bars and percentage indicator (only when connection to the carrier's network is established) Note:...
  • Page 50 USING CONNECTION MANAGER Settings tab Use the Settings tab to specify the type of device: USB Modem or Serial Modem. If USB Modem is selected, the tab displays USB settings. These settings cannot be edited. If Serial Modem is selected, the tab displays the serial settings that match the serial-port settings for the device.
  • Page 51 USING CONNECTION MANAGER Try the following steps: Click the Settings tab and make sure that the appropriate modem type is selected: USB or Serial. If you are connecting a serial device, make sure that all serial modem settings correspond to the serial modem and serial port configuration.
  • Page 52 INDEX Index documentation..............6 activation...............44 antenna .................23 cellular devices............22 electrical characteristics, pins ........16 diversity..............24 GPS................25 LTE................22 AT#SHDN ...............15 grant notes...............25 FCC certification ............31 MTSMC-LVW2 ............33 build options ..............7 MTSMC-LVW2-U ............33 FCC Notice Class B ..............30 certification FCC ..............31 33 Industry Canada ..........34 36 GPS ................15 Chinese hazardous substances antenna..............25...
  • Page 53 INDEX maintenance ..............29 safety mechanical drawings............8 9 RF interference ............27 model location ..............42 vehicle..............28 mounting hardware ............21 shutdown ..............15 MTSMC-LAT1..............19 specifications............10 11 12 MTSMC-LAT1-U.............19 static................27 MTSMC-LEU1 ..............20 sécurité MTSMC-LEU1-U.............21 interférences RF............27 MTSMC-LVW2 .............20 33 36 MTSMC-LVW2-U ..........20 33 36 troubleshooting Connection Manager ..........50 power down ..............15 power draw............19 20 21...
