REAR COMBINATION LAMP

Turn Signal Lamp,
Tail Lamp, Stop Lamp
1. Disconnect the negative cable
on the battery.
2. Open the tailgate and disconnect
two mounting bolts.
14-6
Page 6
Stop lamp
Turn signal lamp
Tail lamp
3. Disconnect the connector and
remove the rear combination
lamp housing.
4. Turn the lamp connector to re-
move it from the rear combina-
tion lamp housing.
2006-10-02, ¿ÀÀü 11:08
5. Remove the bulb from the lamp
connector while pushing and
turning it.
6. Install the new bulb in the re-
verse order of removal.
